OPTIONAL FEATURES
WALL MOUNTING
Use the threaded inserts on the back of your DTV to
secure it using a wall mounting kit. (VESA standard inter-
face 100 x 100.)
Note: Wall Mounting kit is not supplied.
LCD Mounting screws measurements:
M4 Diameter, Length—10mm (maximum).
DETACHING THE TV TILT STAND
Tools Needed: Phillips screwdriver
Important Note: Place DTV face down on a padded
or cushioned surface to protect the screen and finish.
1
Remove two (2) screws from the metal bracket.
CAUTION: Hold the stand firmly as you remove the
last screw.
2
Carefully remove the DTV stand.
DTV BACK VIEW
USING THE DETACHABLE TV TILT
STAND
To change the viewing angle of your TV, position your
hand on the top and hold the stand firmly, then tilt the
LCD screen forward or backward. CAUTION: Do not
position hand under the screen while tilting the TV
forward.
