Chassis Electrical Parts List
Product safety should be considered when a component replacement is made in any area of a receiver.
Components indicated by a
!
mark in this parts list and the circuit diagram show components whose value have
special significance to product safety. It is particularly recommended that only parts specified on the following parts
list be used for components replacement pointed out by the mark.
Ref. No. Part No.
Description
Ref. No.
Part No.
Description
Note: Parts order must contain Service Ref. No., Part No., and descriptions.
Safety
Safety
A013 013N7TV ELECTRICAL PARTS DIRECTORY
EL901 1AV4T40C14600 LCD(T315HW02 V0)
SP901 1LB4A10B12100 SPEAKER,8
SP902 1LB4A10B12100 SPEAKER,8
WSP9L 1LB9W03CM001E NONSTANDARD WIRE ASSY
1LB4J11YA030N SOCKET,HOUSING 3P
1LB4J30B0010N TERMINAL,SOCKET
WSP9R 1LB9W02CM001F NONSTANDARD WIRE ASSY
1LB4J11YA020N SOCKET,HOUSING 2P
1LB4J30B0010N TERMINAL,SOCKET
W1601-80 1LB9W0ECM005H NONSTANDARD WIRE ASSY
1LB4J11YA040N SOCKET,HOUSING 4P
1LB4J11YA100N SOCKET,HOUSING 10P
1LB4J11YA140N SOCKET,HOUSING 14P
1LB4J30B0010N TERMINAL,SOCKET
W1603-66 1AA99CM07360X STANDARD WIRE ASSY-JPN
W1606-66 1AA9ECM07360X STANDARD WIRE
W7200 1LB4W30B21900 CORD 51PIN (LVDS)
W802-190 1AA97AYBE440Z STANDARD WIRE ASSY-JPN
W901 1LB4W10B03700 CORD,POWER-2415MM
A1000 1LG0B10Y047A0 ASSY,PWB,MAIN COMP N7TV
A1001 1LG0B10Y047AA ASSY,PWB,MAIN N7TV
A101 1LB4F1BGZ0020 TUNERU/V
C001 CK1A105KGQBNG CERAMIC 1U K 10V
C001 CK1A105KLZBNG CERAMIC 1U K 10V
C002 CKXLB1H103YAG CERAMIC 0.01U K 50V
C002 CK1H103KGQBNG CERAMIC 0.01U K 50V
C002 CK1H103KLZBNG CERAMIC 0.01U K 50V
C003 CK1A105KGQBNG CERAMIC 1U K 10V
C003 CK1A105KLZBNG CERAMIC 1U K 10V
C004 CK1A105KGQBNG CERAMIC 1U K 10V
C004 CK1A105KLZBNG CERAMIC 1U K 10V
C006 CK1A105KGQBNG CERAMIC 1U K 10V
C006 CK1A105KLZBNG CERAMIC 1U K 10V
C007 CK1A105KGQBNG CERAMIC 1U K 10V
C007 CK1A105KLZBNG CERAMIC 1U K 10V
C008 CK1A105KGQBNG CERAMIC 1U K 10V
C008 CK1A105KLZBNG CERAMIC 1U K 10V
C009 CEXLB1H1R0VDN ELECT 1U M 50V
C011 CK1A105KGQBNG CERAMIC 1U K 10V
C011 CK1A105KLZBNG CERAMIC 1U K 10V
C013 CK1C105ZGAFNG CERAMIC 1U Z 16V
C014 CK1A105KGQBNG CERAMIC 1U K 10V
C014 CK1A105KLZBNG CERAMIC 1U K 10V
C016 CK1A105KGQBNG CERAMIC 1U K 10V
C016 CK1A105KLZBNG CERAMIC 1U K 10V
C017 CK1A105KGQBNG CERAMIC 1U K 10V
C017 CK1A105KLZBNG CERAMIC 1U K 10V
C018 CK1A105KGQBNG CERAMIC 1U K 10V
C018 CK1A105KLZBNG CERAMIC 1U K 10V
C019 CEXLB1H220VDN ELECT 22 U M 50V
C021 CK1A105KGQBNG CERAMIC 1U K 10V
C021 CK1A105KLZBNG CERAMIC 1U K 10V
C022 CEXLB1C221VDN ELECT 220U M 16V
C023 CEXLB1C221VDN ELECT 220U M 16V
C024 CK1A105KGQBNG CERAMIC 1U K 10V
C024 CK1A105KLZBNG CERAMIC 1U K 10V
C027 CEXLB1E471VEN ELECT 470U M 25V
C028 CK1E105KGQBNG CERAMIC 1U K 25V
C029 CKXAV1H104EAG CERAMIC0.1U K 50V
C029 CKXLB1H104YAG CERAMIC 0.1U K 50V
C029 CK1H104KGQBNG CERAMIC 0.1U K 50V
C029 CK1H104KLZBNG CERAMIC 0.1U K 50V
C031 CK1E224KLZBNG CERAMIC 0.22U K 25V
C032 CKXAV1H104EAG CERAMIC0.1U K 50V
C032 CKXLB1H104YAG CERAMIC 0.1U K 50V
C032 CK1H104KGQBNG CERAMIC 0.1U K 50V
C032 CK1H104KLZBNG CERAMIC 0.1U K 50V
C033 CK1H474KGABNG CERAMIC 0.47U K 50V
C033 CK1H474ZGBFNG CERAMIC 0.47U Z 50V
C034 CKXAV1H104EAG CERAMIC0.1U K 50V
C034 CKXLB1H104YAG CERAMIC 0.1U K 50V
C034 CK1H104KGQBNG CERAMIC 0.1U K 50V
C034 CK1H104KLZBNG CERAMIC 0.1U K 50V
C036 CKXAV1H104EAG CERAMIC0.1U K 50V
C036 CKXLB1H104YAG CERAMIC 0.1U K 50V
