Sanyo PID-42AE1 User Manual

17
SPECIFICATIONS/HELPFUL HINTS
Specication
Common specication
Power source: 100 ~ 240V 50Hz/60Hz
Colour system: PAL/NTSC/NTSC4.43/SECAM
AV terminal
AV1: Scart CENELEC Standard
Input: Composite video, RGB (5V RGB with 5V sync to pin 14)
and audio-L/R
Output: composite video from AV3 and audio L/R
AV2: BNC
Input: RGB, H and V/Y, Pb, Pr and audio L/R
Output: RGB, H and V/Y, Pb, Pr
AV3: BNC
Input: Composite video
Output: Composite video
Audio Monitor Out: CINCH L/R
Audio Speaker Out: 2 x 6W
DVI
Input: DVI-D GROUP Standard
PC
Input: Mini D-SUB 15 PIN and Audio 3.5mm Jack
Serial Port: RS232C: Input/Output
Helpful hints
■ NO PICTURE NO SOUND
● Check if monitor is plugged in.
● Check monitor is not in standby mode.
■ POOR PICTURE
● Adjust BRIGHTNESS/CONTRAST levels (too low).
■ NO COLOUR, PICTURE OK
● Adjust COLOUR control.
● Check lead connections.
● Does the signal input have colour.
■ REMOTE CONTROL DOES NOT WORK
● Check batteries are inserted correctly.
● Check condition of batteries.
● Check to see if remote control inhibit is set ON.
■ PICTURE OK, NO SOUND
● Check external speakers are connected correctly.
● Check lead connections to external equipment.
● Check volume turned down or mute selected.
Model name Contrast Ratio
Screen
(inches/cm)
(viewing measured
diagonally)
Display Native
Resolution
Veiwing angles
Dimension
(W x H x D)
Weight (kg)
PID-42AE1
1000:1 42"/106.7 cm 1920 x 1080 H: 178°, V: 178° 1010.3 x 603.3 x 100 mm 18
PID-42AS1
● The specications are subject to change without notice.
● LCD panels are manufactured to the highest possible standards. Even though 99.99% of the pixels are effective, a tiny fraction of the pixels
(0.01% or less) may be ineffective by the characteristics of the LCD panels.
GB GB
