9
Part Names and Functions
Bottom
Back
Front
q Power Cord Connector
w Infrared Remote Receiver
e Zoom Lever
r Focus Ring
t Projection Lens
y Lens Cover (See page 54 for attaching.)
u Air Intake Vent
q w e r t
q Exhaust Vent
q
w e r
q Lamp Cover
w Air Intake Vent (back and bottom)
e Air Filter
r Adjustable Feet
r
q ew
w Top Controls and Indicators
e Air Intake Vent
r Terminals and Connectors
t Speaker
CAUTION
Hot air is exhausted from the exhaust
vent. Do not put heat-sensitive
objects near this side.
y u
t
