- 53 -
No. Adjustment Item Initial Value Range Input source / Description
Group: 0 AD Converter (PW392)
10 SOGTH 3/3/4 0 - 15 PC / Component / SCART SyncOn Green Threhould
11 SOGHYSDIS 1/1/0 0 - 1 PC / Component / SCART SyncOn Green Hsysterisis Enable
12 HS1TH 4 0 - 7 H Sync1 Threshold
13
HS0TH 4 0 - 7 H Sync0 Threshold
20 Anti-alias Filter
G1 - 4
G2 - 4
G3 - 6
G4 - 5
G5 - 4
G6 - 4
G7 - 4
0 - 7
Setting Group
Group1 : PC (Read Only)
Group2 : Sxart (Read Only)
Group3 : YCbCr 480i, 575i
Group4 : YCbCr 480p, 575p
Group5 : YCbCr 720p 60, 720p 50
Group6 : YCbCr 1080i 60, 1080i 50
Group6 : YCbCr 1080p 60, 1080p 50
21
Anti-alias Down sample
(Read Only)
G1 - 3
G2 - 3
G3 - 0
G4 - 1
G5 -3
G6 - 3
G7 - 3
0 - 3
22
Anti-alias High Friquency
(Read Only)
G1 - 1
G2 - 1
G3 -3
G4 - 1
G5 - 3
G6 - 3
G7 - 3
0 - 3
Group: 20 Video Decoder
10 XCXL Parameter 2 0 - 4 XCXL Leve
11 Sync Amp Low 0x0700 0 - 9999 Minimum sync amplitude threshold for HLOCK 1 to 0 transition
12 Sync Amp High 0x1000 0 - 9999 Minimum sync amplitude threshold for HLOCK 0 to 1 transition
13
Luma Setup Enable 0 0 - 1 7.5IRE Mode (NTSC)
14 Anti-Alias Filter 2 0 - 7 Anti-Alias Filter
15 Anti-Alias Downsample 1 0 - 3 Anti-Alias Downsample
16 Anti-Alias High Frequency 1 0 - 3 Anti-Alias High Frequency
17 CSC Adjust 0x400 / 0x400 0x300 - 0x500 Composite / S-Video - CSC Adjust
20 R3DXL_TB_AMP for PAL 3 0 - 3 R3DXL_TB_AMP for PAL
Group: 40 General
0 IP Mode 1 0 - 1 Setting of IP Off 0: IP Block non used 1: IP Block used IP=0
1 3:2 PullDown Mode 1 1 - 3 bit0 : Global Motion bit1 : Video Motion
2 Detect Film Mode Enable 0 0 - 2
"0 : 2:3pull down & 2:2pull down 1 : 2:3pull down 2 : 2:2pull
down"
3 NR Enable for Analog YUV 1 0 - 1 0: Y & UV Detect Noise reduction 1: Y Detect TUV Noise reduction
4 NR Enable for Digital YUV 0 0 - 1
Analog YUV : PC/Video/S-Video/Component Digital YUV : HDMI
<NSYUVEN>
Group: 41 Deinterlacer Setting Progressive Model 1, Film Parameter
setting
0 Motion Adaptive Weight Value 30/30/30 0 - 255 <KDEINT> Composite / S-Video
1 Angle Interpolation Level 4/4/4 0 - 4 0 : Conservative <====> 4 : Aggressive Component / Scart / PC
2 CUE Low Pass Filter Enable 0/0/0 0 - 1 <CUELPFEN> HDMI
Group: 42 Deinterlacer Setting Setting Progressive Model 2, Parameter
setting
0 Motion Adaptive Weight Value 0/0/0 0 - 255 <KDEINT> Composite / S-Video
1 Angle Interpolation Level 2/2/2 0 - 4 0 : Conservative <====> 4 : Aggressive Component / Scart / PC
2 CUE Low Pass Filter Enable 0/0/0 0 - 1 <CUELPFEN> HDMI
Group: 47 Noise Reduction NR ON, Parameter
setting
Service Adjustment Data Table
These initial values are the reference data written from the CPU
ROM to memory IC when replaced new memory IC. The adjustment
items indicated with “✻” are required to readjust following to the
“Electrical adjustments”. Other items should be used with the initial
data value.
