Sanyo RS1211 / C1211 User Manual

2
WM– 700703
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Remarks: Rating conditions are: Outside air temperature 95°F DB/75°F WB
Indoor unit entering air temperature 80°F DB/67°F WB
2. SPECIFICATIONS
Unit Specifications
Model No.
Indoor unit RS1211
Outdoor unit C1211, CL1211
Cooling
Capacity
BTU/h 11,500
kW 3.37
Air circulation (High) cu. ft./min. 280
Moisture removal (High) pints/h 3.1
Phase, Frequency Hz Single, 60
Voltage rating V 115
Available voltage range V 103 to 127
Running amperes A 11.2
Power input W 1,200
Power factor % 93
Starting amperes A 60
S. E. E. R. BTU/Wh 10.0
Controls Microprocessor
Control unit Wireless remote control unit
Temperature control IC thermostat
Timer ON/OFF 24-hours & Program
Fan speeds Indoor / Outdoor 3 and Auto / 1 (CL1211 Auto)
Air deflector Horizontal / Vertical — / Manual
Air filter Washable, easy access
Compressor Rotary
Refrigerant amount charged at shipment lbs. (kg) R22: 2.66 (1.2)
Refrigerant control Capillary tube
Refrigerant tubing connections Flare type
Operation sound
In-Hi / Me / Lo dB-A 45 / 43 / 41
Out-Hi dB-A 49
Max. allowable tubing length at shipment ft. (m) 33 (10)
Limit of tubing length ft. (m) 65 (20)
Limit of elevation difference ft. (m) Outdoor unit is higher than indoor unit: 23 (7)
between the 2 units Outdoor unit is lower than indoor unit: 23 (7)
Refrigerant tube o.d.
Narrow tube in. (mm) 1/4 (6.35)
Wide tube in. (mm) 1/2 (12.7)
Refrigerant tube kit Optional
Accessories Mounting bracket
Indoor unit Outdoor unit
Height in. (mm) 12-5/8 (320) 20-7/8 (530)
Width in. (mm) 31-29/32 (810) 29-17/32 (750)
Depth in. (mm) 24-13/32 (620) 11-1/32 (280)
Net weight lbs. (kg) 68 (30.8) 90.4 (41)
Shipping volume cu. ft. (cu. m) 11.7 (0.329) 6.7 (0.19)
Shipping weight lbs. (kg) 99 (44.6) 97.1 (44)
Performance
Electrical Rating
Features
Dimensions & Weight
