23
Adjusting the Airflow Direction
• The flap automatically closes when the unit is off.
• During the heating operation, the fan speed will be very low and the flap
will be in the horizontal position (position ) until the air being blown out
of the unit begins to warm. Once the air warms up, the flap position and
fan speed change to the settings specified with the remote control.
• Use the FLAP button on the remote control to adjust the position of
the flap. If you move the flap by hand, the flap position according to
the remote control and the actual flap position may no longer match.
If this should happen, shut off the unit, wait for the flap to close, and
then turn on the unit again; the flap position will now be normal
again.
• Do not have the flap pointed down during cooling operation.
Condensation may begin to form around the air vent and drip down.
B. Setting the airflow manually
Referring to the above illustration, use the
FLAP button to set the airflow direction
within the range used during the heating,
cooling, or dehumidifying operation.
A. Sweep function
The flap starts moving up and down to
deliver air over the sweep range.
C. Auto flap function
The flap is set to the recommended
position.
NOTE
CAUTION
01_SAP-KRV93EHFP_EN.fm Page 21 Tuesday, November 15, 2005 1:18 PM
HEAT
SWEEP
SWEEP
COOL
and
DRY
This air conditioner is equipped with auto flaps.
You can set the airflow direction using the remote control unit.
6
35
OFF
MODELS XRV
