Sanyo Vizon DP37647 User Manual

— 13 —
Schematic
Location
Part No.
Description
C6516 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6517 CEXLB1V470VDJ ELECT 47U M 35V
C6518 CEXLB1V470VDJ ELECT 47U M 35V
C6519 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6520 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6521 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6522 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6523 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6524 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6525 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C6526 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
DIODES
D801 DD1SS352——G DIODE 1SS352-(TPH3)
D801 DD1SS355——G DIODE 1SS355-TE-17
D803 DZUDZS3.9B—G ZD UDZS-TE-173.9B
D804 DZUDZS6.2B—G ZD UDZS-TE-176.2B D1611
DDD1FM3——-G DIODE D1FM3
D1612 DDD1FM3——-G DIODE D1FM3
D1613 DDD1FH3——-G DIODE D1FH3
D1620 DZUDZS3.0B—G ZD UDZS3.0B-TE-17
D1621 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
D1641 DDD1FM3——-G DIODE D1FM3
D1663 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
D1671 DD1SS352——G DIODE 1SS352-(TPH3)
D1671 DD1SS355——G DIODE 1SS355-TE-17
D1677 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
D1681 DDD1FM3——-G DIODE D1FM3
D1683 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
D1902 DLSLR343MC3FN LED SLR-343MC3F
D3216 DDRB551V-30-G DIODE RB551V-30 TE-17
D6051 DZUDZS3.0B—G ZD UDZS3.0B-TE-17
D6052 DD1SS352——G DIODE 1SS352-(TPH3)
DD1SS355——G DIODE 1SS355-TE-17
INTEGRATED CIRCUITS
IC001 QLA42205-E—N IC LA42205-E
IC800 QXXAAJQ0858— ICLC87F5932AU-Y08LCD
IC800A QXXAVC974—-M ICLC87F5932AU-QIP-E
IC801 QXXAVC844—-P ICCAT24C04WI-GT3
QLE24C042M-EP ICLE24C042M-TLM-E
QXXAVC820—-P ICAT24C04N-10SU-1.8
IC802 QTC7SET08FU-P IC TC7SET08FU
IC803 QTC7SH08FU—P ICTC7SH08FU(TE85L)
IC1251 QCD4052BNSR-P IC CD4052BNSR
QTC4052BF—-P IC TC4052BF-EL
IC1600 QBD9842FV—-P IC BD9842FV-E2
IC1610 QLA5774MPE—P ICLA5774MP-DL-E
IC1650 QMP2106DK—-P IC MP2106DK
IC1670 QXXAVC692—-P ICPQ1LAX95MSPQ
IC1681 QLA5774MPE—P ICLA5774MP-DL-E
IC1691 QPST600DMT—P IC PST600DMT
IC3200 QNJW1142CV—P IC NJW1142CV
IC5500 QXXAVC970—-M IC215-0619000-00
IC5700 QXXAVC967—-P ICHYB18T512161B2F-25
IC5750 QXXAAJQ0880— ICNAND128W3A2BN6E N4VJ
IC5750A QXXAVC973—-M ICNAND128W3A
IC5900 QM51957BFP—P IC M51957BFP
IC6051 QPQ070XNA1ZPP ICPQ070XNA1ZPH
IC6060 QXXAVC976—-P ICPQ018EN02ZPH
IC6071 QPQ070XNA1ZPP ICPQ070XNA1ZPH
IC6200 QNJM4558M—-P ICNJM4558M-TE2
IC6270 QXXAVC944—-P ICWM8781GEDS/R
IC6504 QXXAVC972—-M IC SII9185A
COILS
L001 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L002 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L003 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L004 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L005 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L006 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L801 1AV4L2FB3R3MG “INDUCTOR,3.3U M”
L802 1AV4L2FB3R3MG “INDUCTOR,3.3U M”
L803 1LB4L26B0740G “INDUCTOR ,220 OHM”
L804 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L805 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L1000 1AV4L2FB3R3MG “INDUCTOR,3.3U M”
L1202 1AV4L2FB3R3MG “INDUCTOR,3.3U M”
L1601 1LB4L26B0740G “INDUCTOR ,220 OHM”
L1602 1LB4L26B0740G “INDUCTOR ,220 OHM”
L1603 1LB4L26B0740G “INDUCTOR ,220 OHM”
L1604 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L1605 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L1608 1LB4L26B0740G “INDUCTOR ,220 OHM”
L1609 1LB4L26B0740G “INDUCTOR ,220 OHM”
L1612 1LB4L26B0740G “INDUCTOR ,220 OHM”
L1613 1LB4L26B0740G “INDUCTOR ,220 OHM”
L1614 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L1615 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L1616 1AV4L26B5930N “INDUCTOR,10U”
L1617 1LB4L26B1000N “INDUCTOR,15UH”
1AV4L2WK150MN “INDUCTOR,15U M”
L1618 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L1619 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L1620 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L1621 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L1622 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L1623 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L1624 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
L1625 RGFR000ZTAANL MT-GLAZE 0.000 ZA1/10W
Schematic
Location
Part No.
Description
