CONNECTING TO A TV
OTHER DEVICES AND CONNECTIONS
CONNECTING TO A TV
CONNECTING TO A TV
CONNECTING TO A TV
CAUTION
Insert and pull out the cable carefully
i When connecting the cables, make sure that the cable plugs are correctly
oriented and that they match the shapes of the terminal sockets on the
devices. Push the plugs in straight when connecting them. If undue force is
used to connect a cable, it may permanently damage the connector pins in
the terminal socket.
i Do not use excessive force when connecting and disconnecting cables.
About image output: The image output destination differs depending on the
camera status.
m: Images are output n: Images are not output
Connection
cable
Image output
destination
Recording mode
Playback
mode
Standby Recording
Dedicated AV
interface cable
Camera monitor
NTSC: m
PA L : m
mm
TV
NTSC: m
PA L : n
nm
Dedicated
component
cable
Camera monitor nmn
TV mnm
