Device description (Fig.1)
1 Motor housing
2 Handle
3 ON- / OFF switch
4 Additional handle
5 Tool holder
6 Locking bolt
7 Oil ll opening / sight glass
8 Point chisel
Scope of delivery (Fig.1.1)
Demolition Hammer (1x)
Transport box (1x)
Point-chisel ø 30 L390 (1x) (C)
Flat-chisel ø 30 L390 (1x) (D)
Oil can (1x) (G)
Maintenance-tool (1x) (F)
Replacement-Motor~/Carbon brush (2x)
(E)
Instruction manual (1x)
• Open the packaging and remove the de-
vice carefully.
• Remove the packaging material as well
as the packaging and transport bracing
(if available).
• Check that the delivery is complete.
• Check the device and accessory parts
for transport damage. When complaints
the dealer must be informed immediate-
ly. Subsequent complaints will not be ac-
cepted.
• If possible, store the packaging until the
warranty period has expired.
• Read the operating instructions to make
yourself familiar with the device prior to
using it.
• Only use original parts for accessories
as well as for wearing and spare parts.
Spare parts are available from your spe-
cialized dealer.
• Specify our part numbers as well as the
type and year of construction of the de-
vice in your orders.
m Attention!
The device and packaging materials are
not toys! Children must not be allowed
to play with plastic bags, lm and small
parts! There is a risk of swallowing and
suffocation!
Intended use
The machine is intended for heavy chisel-
ling and demolition work as well as for driv-
ing in and compacting with the appropriate
accessories.
The equipment is allowed to be used only
for its prescribed purpose. Any other use is
deemed to be a case of misuse. The user/
operator and not the manufacturer will be
liable for any damage or injuries of any kind
resulting from such misuse.
An element of the intended use is also the
observance of the safety instructions, as
well as the assembly instructions and oper-
ating information in the operating manual.
