inatable dinghies, air mattresses, balls etc.
Pressure can be released by actuating the vent valve (7).
m Attention! The manometer has not been ofcially
calibrated! After inating, please check the air pressure
with a calibrated device.
Using an air blow gun
You can also use the tyre ination device (G) as an air
blow gun to clean out cavities and to clean soiled sur-
faces and work equipment.
To do so, please rst remove the hose with the valve
adapter (8).
Now screw the blow-out adapter (D) to the tyre ination
device (G).
Using the adapter set
The adapter set enables you to use the following addi-
tional capabilities of the tyre ination device:
• Pumping up balls with the help of the ball needle (F).
• The valve adapter (E) enables bicycle tyres to be in-
ated.
• Filling pools, air mattresses or boats with the help of
the additional adapter (K).
• Filling items with threaded valves (e.g. Boats) with the
screw-in valve adapter (J).
• Deating large volume items. The deating adapter
(C) can be used for this.
• The two conical universal adapters (A/B) can likewise
be used for inating air mattresses.
Electrical connection
The electrical motor installed is connected and
ready for operation. The connection complies with
the applicable VDE and DIN provisions.
The customer‘s mains connection as well as the
extension cable used must also comply with these
regulations.
Damaged electrical connection cable
The insulation on electrical connection cables is often
damaged.
This may have the following causes:
• Passage points, where connection cables are passed
through windows or doors.
• Kinks where the connection cable has been improp-
erly fastened or routed.
• Places where the connection cables have been cut
due to being driven over.
• Insulation damage due to being ripped out of the wall
outlet.
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not be
used and are life-threatening due to the insulation damage.
Check the electrical connection cables for damage reg-
ularly. Make sure that the connection cable does not
hang on the power network during the inspection.
Electrical connection cables must comply with the ap-
plicable VDE and DIN provisions. Only use connection
cables with the marking „H05VV-F“.
Before starting the equipment
Before you connect the equipment to the mains supply
make sure that the data on the rating plate are identical
to the mains data.
• Check the equipment for damage which may have
occurred in transit. Report any damage immediately
to the transport company which was used to deliver
the compressor.
• Install the compressor near the point of consumption.
• Avoid long air lines and supply lines (extension ca-
bles).
• Make sure that the intake air is dry and dustfree.
• Do not install the compressor in a damp or wet room.
• The compressor may only be used in suitable rooms
(with good ventilation and an ambient temperature from
+5 °C to 40 °C). There must be no dust, acids, vapors,
explosive gases or inammable gases in the room.
• The compressor is designed to be used in dry rooms.
It is prohibited to use the compressor in areas where
work is conducted with sprayed water.
Attachment and operation
n Important!
You must fully assemble the appliance before using
it for the rst time!
Mains connection
• The compressor can be connected to any 220 - 240-
240 V~ 50 Hz shock-proof socket which is protected
by a 16 A fuse.
• Before you use the machine, make sure that the
mains voltage is the same as the operating voltage
(see the rating plate).
• Long supply cables, extensions, cable reels etc. cause
a drop in voltage and can impede motor start-up.
• At low temperatures below +5°C, sluggishness may
make starting difcult or impossible.
ON/OFF switch (g. 1)
• To switch on the compressor, press the button (2) on
position I.
• To switch off the compressor, press the button (2) on
position 0.
Establishing connections (g. 2-4)
m Attention! Switch the device off for this.
When doing so, hold the coupling rmly in order to avoid
injuries due to the hose springing back.
• First connect the air hose (5) with the quick coupling
of your compressor.
• Connect the tting of your compressed air tool to the
compressed air hose (5) of the compressor.
• To disconnect this coupling again, pull the quick-cou-
pling (4) back at the compressed air hose (5).
Using the tyre ination device (g. 6, 7, 8)
The compressed air tyre ination device (G) is used to
inate car tyres. With the corresponding accessories it
can also be used to inate and regulate bicycle tyres,
