Scheppach deco 401 User Manual

english 9
Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear customer,
we wish you a pleasant and successful working experience
withyournewscheppachcircularsawforrewood.
According to the applicable product liability law the manu-
facturer of this device is not liable for damages which arise
on or in connection with this device in case of:
• improperhandling
• noncompliancewiththeinstructionsforuse
• repairsbythirdparty,nonauthorizedskilledworkers
• installationandreplacementofnonoriginalspareparts
• improperuse
• failuresoftheelectricalsystemduetothenoncompli-
ancewiththeelectricalspecicationsandtheVDE0100,
DIN57113/VDE0113regulations
m
Recommendations:
Read the entire text of the operating instructions prior to the
assembly and operation of the device.
These operating instructions are intended to make it easier
for you to get familiar with your device and utilize its in-
tended possibilities of use.
The operating instructions contain important notes on how
to work safely, properly and economically with your ma-
chine and how to avoid dangers, save repair costs, reduce
downtime, and increase the reliability and working life of
the machine.
In addition to the safety regulations contained herein, you
must in any case comply with the applicable regulations of
your country with respect to the operation of the machine.
Put the operating instructions in a clear plastic folder to
protect them from dirt and humidity, and store them near
the machine. The instructions must be read and carefully
observed by each operator prior to starting the work. Only
persons who have been trained in the use of the machine
and have been informed on the related dangers and risks
areallowed touse the machine. The required minimum
age must be met.
In addition to the safety notes contained in the present
operating instructions and the special regulations of your
country, the generally recognized technical rules for the
operation of wood working machines must be observed.
General Notes
• Whenyouunpackthedevice,checkallpartsforpossible
transport damages. In case of complaints the supplier is
to be informed immediately.
• Complaintsreceivedatalaterdatewillnotbeacknow
ledged.
• Checkthedeliveryforcompleteness.
• Readtheoperatinginstructionstomakeyourselffamil-
iar with the device prior to using it.
• Onlyuseoriginalscheppachpartsforaccessoriesaswell
as for wearing and spare parts. Spare parts are available
from your specialized dealer.
• Specifyourpartnumbersaswellasthetypeandyearof
construction of the device in your orders.
Warning
Toavoidelectricalhazards,rehazards,ordamagetothe
tool, use proper circuit protection.
Yourdrillpressiswiredatthefactoryfor230Voperation.
Connecttoa230V/15ampbranchcircuitandusea15
amp time delay fuse or circuit breaker. To avoid shock or
re,replacepowercordimmediatelyifitisworn,cutor
damaged in any way.
deco-tronic 401 402
Technical data
Dimensions
L x W x H mm
630 x 290
x 320
620 x 320
x 320
620 x 320
x 320
Bench size mm
ø 250 x 410 ø 250 x 410 ø 250 x 410
Saw blade
length mm
133 133 133
Cutting height
max. mm
50 50 50
Working depth mm
400 400 400
Lifting
movement mm
14 14 14
Lifting speed 1/
min (electronical)
400 – 1600 1450 900/1450
Bench diagonal
adjustment left
degrees
0 – 45 0 – 45 0 – 45
Weight kg
11,5 15 15
Suction
connection
piece ø mm
35 35 35
Motor
Electrical motor
230V/50Hz 230V/50Hz 230V/50Hz
Power
consumption P1 W
90 150 150/200
Sound pressure
level on oper at-
or’s ear measured
in accordance
with DIN 45635
with max. speed
during idle
running
76dB(A) 76dB(A) 76dB(A)
Special accessories
Pin saw blade-universal
135 x 2,0 x 0,25 Z 10
blademm1set=6pieces,ArticleNo.8800 0011
Pinsawbladewood/plasticmm
135x2,0x0,25Z7
1set=6pieces,ArticleNo.8800 0012
Pin saw blade-wood mm
135 x 3,0 x 0,5 Z 4
1set=6pieces,ArticleNo.8800 0013
m
In these operating instructions we have marked
the places that have to do with your safety with
this sign.
General Safety Rules
WARNING! When using electric tools basic safety pre -cautions
should always be followed to reduce the risk of fire, electric
shock and personal injury.
Readall theseinstructions before attempting to operate
this product. Save these instructions for future reference.
• Keepworkareaclear.Clutteredareasandbenchesinvite
injuries.
