11. Disposal and recycling
The unit is supplied in packaging to prevent
its being damaged in transit. This packaging
is raw material and can therefore be reused
or can be returned to the raw material system.
The unit and its accessories are made of var-
ious types of material, such as metal and plas-
tic. Defective components must be disposed of as spe-
cial waste. Ask your dealer or your local council.
Old devices must not be disposed of with house-
hold waste!
This symbol indicates that this product must
not be disposed of together with domestic
waste in compliance with the Directive
(2012/19/EU) pertaining to waste electrical
and electronic equipment (WEEE). This product must
be disposed of at a designated collection point. This
can occur, for example, by handing it in at an author-
ised collecting point for the recycling of waste electri-
cal and electronic equipment.
Improper handling of waste equipment may have neg-
ative consequences for the environment and human
health due to potentially hazardous substances that
are often contained in electrical and electronic equip-
ment. By properly disposing of this product, you are al-
so contributing to the effective use of natural resourc-
es. You can obtain information on collection points for
waste equipment from your municipal administration,
public waste disposal authority, an authorised body for
the disposal of waste electrical and electronic equip-
ment or your waste disposal company.
Dispose of the old oil at a drop-off point for old oil.
To ll in the correct quantity of oil, make sure that the
compressor stands on an even surface. Fill new oil
through the oil ller opening (19) until it comes up to
the maximum level. This is marked with a red dot on
the oil level window (12) (Fig. 11). Do not exceed the
maximum lling quantity. Overlling the equipment
may result in damage. Reinsert the oil sealing plug (15)
into the oil ller opening (19).
10.6 Cleaning the intake lter (Fig. 3, 12, 13)
The intake lter prevents dust and dirt being drawn in.
It is essential to clean this lter after at least every 300
hours in service. A clogged intake lter will decrease
the compressor’s performance dramatically. Open the
screw (E) to remove the intake lter (2x).
Then pull off the lter cover (D). Now you can remove
the air lter (F). Carefully tap out the air lter, lter cov-
er and lter housing. Then blow out these parts with
compressed air (approx. 3 bar) and reinstall in reverse
order.
10.7 Storage
m Important!
Pull out the mains plug and ventilate the equip-
ment and all connected pneumatic tools. Switch
off the compressor and make sure that it is se-
cured in such a way that it cannot be started up
again by any unauthorized person.
m Important!
Store the compressor only in a dry location which
is not accessible to unauthorized persons. Always
store upright, never tilted! Oil may leak out!
10.7.1 Releasing excess pressure
Release the excess pressure by switching off the com-
pressor and using the compressed air which is still left
in the pressure vessel, e.g. with a compressed air tool
running in idle mode or with a blow-out pistol.
10.8 Service information
Please note that the following parts of this product are
subject to normal or natural wear and that the following
parts are therefore also required for use as consum-
ables.
Wear parts*: belt, coupling
* Not necessarily included in the scope of delivery!
Spare parts and accessories can be obtained from our
service centre. To do this, scan the QR code on the
cover page.
