Scheppach ROBOCUT XL600 User Manual

www.scheppach.com
GB
|
27
IP protection classes
Robot mower IPX5
Charge station IPX4
Mains power unit IP67
Total weight (net) approx. 8 kg
Technical changes reserved!
m IMPORTANT:
This charging unit is suitable exclusively for charging
the product type RoboCut XL600.
Noise & vibration
m Warning: Noise can have serious e󰀨ects on your
health. If the machine noise exceeds 85 dB, please
wear suitable hearing protection.
Device emissions values
Measured sound power level L
WA
50.36 dB
Uncertainty K
WA
4.09 dB
Guaranteed sound power level L
WA
55 dB
Sound pressure level L
pA
44 dB
Uncertainty K
pA
3 dB
The noise emission declaration complies with stand-
ard EN ISO 3744
7. Unpacking
• Open the packaging and carefully remove the prod-
uct.
• Remove the packaging material, as well as the
packaging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for trans-
port damage. In the event of complaints the carrier
must be informed immediately. Later claims will not
be recognised.
• If possible, keep the packaging until the expiry of
the warranty period.
• Familiarise yourself with the product by means of
the operating manual before using for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Replace-
ment parts can be obtained from your dealer.
• When ordering please provide our article number
as well as type and year of manufacture for the
product.
m ATTENTION!
The device and the packaging material are not
children‘s toys! Do not let children play with
plastic bags, lms or small parts! There is a dan-
ger of choking or su󰀨ocating!
8. Assembly / Before commissioning
m ATTENTION!
Always make sure the product is fully assembled
before commissioning!
m ATTENTION!
If you intend to use a scarier within the working
area of the robotic mower, the boundary wire (11)
must be buried.
m ATTENTION!
Do not use a strimmer near the boundary wire
(11). Take care when trimming edges near which
the boundary wire (11) is located.
8.1 Setting up / correct position of the charging
station (10)
m ATTENTION
Fix the charging station (10) in place with the
help of a hammer (not included in delivery) and
the anchor pegs (13) only after you have staked
out the complete working area.(Fig. 16).
m NOTE:
Do not make new holes in the charging station.
m NOTE:
Do not stand with your feet on the charging station
plate.
m ATTENTION
The extension cable as well as the mains cable
must be outside the working area to ensure that
it is not damaged.
• The charging station (10) can be placed near a
shed, a garden shed or the house.
• The charging station (10) must be placed on lev-
el ground.
m NOTE:
Do not place the charging station (10) on a slop-
ing or uneven surface, otherwise it will bend and
the function will be impaired or a defect may occur.
• The charging station (10) must be set up/positioned
such that there is at least one metre of space in
front of the charging station (10), without obstacles
or similar. (Fig. 3)
