13 14
.
10 Maintenance
11 Specifications
Cleaning and Storing Your miniLITE
Use a soft, wet cloth to wipe the mainframe clean. Hard to remove dirt can be scrubbed with a toothbrush and toothpaste,
then cleaned with a soft, wet cloth. Scratches on plastic parts can be polished with extra fine grit abrasive paper.
NOTE
Do not wash your miniLITE with alcohol, gasoline, acetone, or other corrosive/volatile solvents. These substances may
damage the appearance and internal structure of your miniLITE. Do not wash your miniLITE with a power washer or high
pressure hose.
WARNING
Make sure the miniLITE is powered OFF, the charging cable is unplugged, and the rubber cap on the charge port is tightly
sealed before cleaning; otherwise you may expose yourself to electric shock or damage the electronic components.
Store your miniLITE in a cool, dry place. Do not store it outdoors for extended periods of time. Exposure to sunlight and
temperature extremes (both hot and cold) will accelerate the aging process of the plastic components and may reduce
battery life.
Tire Pressure
Inflate tires to 45–50 psi. Inflate both tires equally.
Battery Pack Maintenance
Do not store or charge the battery at temperatures outside the stated limits (see Specifications). Do not discard or destroy
the battery. For more battery information, refer to the sticker on the battery itself, located on the bottom of the miniLITE.
Refer to your local laws and regulations regarding battery recycling and/or disposal.
A well maintained battery can perform well even after many miles of riding. Charge the battery after each ride and avoid
draining the battery completely. When used at room temperature (70°F [22°C]) the battery range and performance is at its
best; whereas using it at temperatures below 32°F (0°C) can decrease range and performance. Typically, at -4°F (-20°C)
range can be half that of the same battery at 70°F (22°C). Battery range will recover when temperature rises. More details are
available in the App.
NOTE
Typically, a fully charged battery should retain charge for 120-180 days in Standby Mode. Remember to charge the battery
after each use. Completely draining the battery may cause permanent damage to the battery. Electronics inside the battery
record the charge-discharge condition of the battery; damage caused by over-discharge or under-discharge will not be
covered by the Limited Warranty.
WARNING
Do not attempt to disassemble the battery. Risk of fire. No user serviceable parts.
WARNING
Do not ride when the ambient temperature is outside the machine operation temperature(see Specifications) because
low/high temperature will limit the maximum power/torque. Doing so could cause personal injury or property damage due to
slips or falls.
Item N4M160 Parameters
Dimensions
Unit
Approx. 27.6 lbs (12.5 kg)
Approx. 11 miles (18 km)
10° (80 kg payload) 15° (70 kg payload)
3’7”–5’11” (110–180 cm)
Approx. 10 mph (16 km/h)
Top speed varies to adapt dierent riding manner and remaining battery life.
Top speed will reduce when remaining battery life drops.
Weight
Payload
Net
Rider
Recommended Age
Required Height
Machine
Parameters
Max. Speed
Typical Range
1
Max. Slope
Battery
Motors
Charge Time
21.6×10.4×23.2 in (548×263×590 mm)
22–176 lbs (10–80 kg)
6+ years old. See the weight limit
Pavement, packed dirt, slopes < 10°, obstacles < 0.4 in (1 cm),
gaps < 1.2 in (3 cm)
Traversable Terrain
Operating Temperature
Storage Temperature
IP Rating
Nominal Voltage
Max. Charging Voltage
Charging Temperature
Nominal Capacity
Continuous Discharge Power
2
Battery Management System
Nominal Power
Max. Power
14–104°F (-10–40°C)
-4–122°F (-20–50°C)
Mainframe IP54/ Battery pack IPx6
32–104°F (0–40°C)
36 V DC
42 V DC
155 Wh
1147 W
Over-voltage, under-voltage, short circuit, and over-heating
protection. Auto-sleep and auto-wake.
700×2 W
350×2 W
Approx. 3 hours
[1] Typical Range: tested while riding under full power, 132 lbs (60 kg) load, 77°F (25°C), 6-8 mph (10-13 km/h) average speed on
pavement.
[2] Continuous Discharge Power: tested while under full power at 77°F (25°C). The value changes with temperature and remaining
battery capacity. For example, the continuous discharge power drops to ~80% of the maximum value at 10% remaining battery
capacity, and the continuous discharge power drops to ~70% of the maximum value at 32°F (0°C).
