Sharp 19R-M100 User Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
21
19R-M100
PICTURE TUBE
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by
å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
★ MARK : SPARE PARTS-DELIVERY SECTION
' MARK : X- RAY RELATED PARTS
Ref. No. Part No. ★ Description Code
(MINI NECK)
'åV101 VB48LRH93X/*S J Picture Tube CC
'åDY601 RCiLH0201PEZZ R Deflection Yoke AZ
å L703 RCiLG0078PEZZ R Degaussing Coil AM
or
RCiLG0014MEZZ
or
RCiLG0108GJZZ
or
RCiLG0099PEZZ
LHLDW0003PEKZ R Wire Holder, x4 AB
LHLDW1033PEZZ R Holder AA
PMAGF3045CEZZ J Purity Magnet AG
PSPAG0003PEZZ R Spacer, x3 AD
QEARCA002WJZZ X Grounding Strap
(NORMAL NECK)
'åV101 VB48KRD89X/4E J Picture Tube CB
'åDY601 RCiLHA032WJZZ X Deflection Yoke
å L703 RCiLG0078PEZZ R Degaussing Coil AM
or
RCiLG0014MEZZ
or
RCiLG0108GJZZ
or
RCiLG0099PEZZ
LHLDW0003PEKZ R Wire Holder, x4 AB
LHLDW1033PEZZ R Holder AA
PMAGF3046CEZZ J Purity Magnet AF
PSPAG0003PEZZ R Spacer, x3 AD
QEARCA002WJZZ X Grounding Strap
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
(MINI NECK)
PWB-A DUNTKA358WEY5 – MAIN Unit —
PWB-B DUNTKA359WEW4 – CRT Unit —
(NORMAL NECK)
PWB-A DUNTKA358WEY6 – MAIN Unit —
PWB-B DUNTKA359WEW5 – CRT Unit —
PWB-A: DUNTKA358WEY5 (MINI NECK)
PWB-A: DUNTKA358WEY6 (NORMAL NECK)
MAIN UNIT
TUNER
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
å TU51 VTUVTST5UF740 X Vhf Tuner
or
VTUENV56D82-1
INTEGRATED CIRCUITS
'åIC201 RH-iX3354CEN1 J LA76843N AT
IC351 VHiAN7511//-1 J AN7511 AK
å IC501 VHiLA7840//-1 J LA7840 AR
å IC701 VHiTEA1507/-1 J TEA1507P/N1 AL
å IC702 RH-FX0034CEZZ J PC817 AE
IC771 VHiKA7805AP-1 J KIA7805API AE
or
VHiTA7805S/-1
IC2001 RH-iX3492CEZZQ J TMPA8700CPF AU
IC2040 VHiPST994C/-1+ X PST994C-T
IC2101 VHiM24C16B/-1 J M24C16-BN6 AG
or
VHiBR24C16-1
TRANSISTORS
Q101 VS2SC945AQ/-1+ J 2SC945AQ AB
or
VS2SC3198Y/-1
Q201 VS2SC2735//1EY J 2SC2735 AC
Q451 VS2PB709AR/-1Y J 2PB709AR AB
or
VS2SA812-M51E
Q452 VS2PA1015Y+-1+ J 2PA1015Y AC
Q601 VS2SC2482//-1+ J 2SC2482 AD
å Q602 VS2SD2586//1E J 2SD2586 AM
Q631 VS2SC945AQ/-1+ J 2SC945AQ AB
or
VS2SC3198-Y-1
å Q701 VSSPP04N60C-1 J SPP04N60C AH
or
VS2SK2708//1E
or
VSSPP07N60C-1
or
VSSTP6NC60+-1
or
VSSTP6NC60FP
or
VSSTP7NB60FP
Q702 VS2SC945AQ/-1+ J 2SC945AQ AB
or
VS2SC3198Y/-1
Q751 VS2SC945AQ/-1+ J 2SC945AQ AB
or
VS2SC3198-Y-1
Q752 VS2SC945AQ/-1+ J 2SC945AQ AB
or
VS2SC3198-Y-1
