Sharp 19R-M100 User Manual

8
19R-M100
IC2001
IC2102
(IC2101)
X
CRT
X
IC201
Data is stored in IC2102 (IC2101).
Adjust items related to picture tube only.
Holding down both the Vol-up/Ch-down buttons on the TV set at service mode for more than 2 seconds will automatically
write the above initial values into IC2102 (IC2101).
Table - D
The adjustment is needed to compensate for characteristics
of parts including IC201.
Holding down both the Vol-up/Ch-down buttons on the TV
set in the service mode for more than 2 seconds will
automatically write the above initial values into IC2102
(IC2101).
X
X
ADJUSTMENT
NECESSARY
UNNECESSARY
PART REPLACED
NOTES
R2101 R2102 R2103 R2104
If using
––
IC2101
If using
––
IC2102
Table - E
