Ref. No.Part No.★DescriptionCodeRef. No.Part No.★DescriptionCode
25
32C530
PICTURE TUBE
★ MARK: SPARE PARTS-DELIVERY SECTION
' MARK: X-RAY RELATED PARTS
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics iden-
tified in this manual ; electrical components having such features are
identified by å and shaded areas in the Replacement Parts Lists and
Schematic Diagrams. The use of a substitute replacement part which
does no have the same safety characteristic as the factory recom-
mended replacement parts shown in this service manual may create
shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the fol-
lowing informations.
1. MODEL NUMBER2. REF. NO.
3. PART NO.4. DESCRIPTION
in USA:Contact your nearest SHARP Parts Distributor to order. For
location of SHARP Parts Distributor, Please call Toll-Free; 1-
800-BE-SHARP
Ref. No.Part No.★DescriptionCode
'åV101VB80AKB50X/1E XPicture TubeCD
åL703RCILGA045WJZZ XDegaussing CoilAH
åQEARC3102MEZZ XGrounding StrapAC
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
PWB-ADUNTKB567WEZ5 –MAIN Unit—
PWB-BDUNTKA527WEV6 –CRT Unit—
PWB-DDUNTKB573WEV0 –3 LINE Y/C Unit—
INTEGRATED CIRCUITS
IC101VHiPQ050ES1-1+XPQ050ES1MXPAB
'åIC201VHiTB1253AN-1XTB1253AAP
åIC361VHiAN5277//-1XAN5277AG
åIC501VHITDA8177+-1 XDA81771AE
åIC701VHiTEA1507/-1XTEA1507P/N1AF
åIC702RH-FXA003WJZZXPC123Y82AB
'åIC703VHiSE125N//-1XSE125NAD
IC751VHiPQ09RD11-1XPQ09RD11AD
IC900VHiCXA2089Q-2YXCXA2089Q-6TAK
IC1403VHiPQ05RD11-1XPQ05RD11AD
IC2001RH-iXA418WJZZQXTMP88CS38BFGAN
IC2040VHiKiA7045A-1+XKIA7045APAB
IC2101VHiBR2416E2-1∗XBR24C16FAD
IC3001VHiCXA2074Q-1∗XCXA2074QAP
TRANSISTORS
Q201VS2SC2735//1E∗X2SC2735AB
Q361VS2SB709AR/-1∗X2SB709ARAB
Q401VS2SD601AR/-1∗X2SD601ARAB
Q402VS2SB709AR/-1∗X2SB709ARAB
Q403VS2SD601AR/-1∗X2SD601ARAB
Q404VS2SD601AR/-1∗X2SD601ARAB
Q451VS2SA1266-Y-1+X2SA1266-YAB
Q460VSRT1N441C/-1∗XRT1N441CAB
Q601VS2SC2482//-1+X2SC2482AB
åQ602VS2SD2581++2E XSD2581++ AG
åQ701VSSPA11N603-1 XSPA11N603 AK
Q751VS2SC3198-G-1+X2SC3198-GAB
Q755VS2SD601AR/-1∗X2SD601ARAB
Q756VS2SD601AR/-1∗X2SD601ARAB
Q757VS2SC3198-G-1+X2SC3198-GAB
Q758VS2SA1266-Y-1+X2SA1266-YAB
Q802VS2SD601AR/-1∗X2SD601ARAB
Q901VS2SD601AR/-1∗X2SD601ARAB
Q902VS2SD601AR/-1∗X2SD601ARAB
Q903VS2SD601AR/-1∗X2SD601ARAB
Q904VS2SD601AR/-1∗X2SD601ARAB
Q905VS2SD601AR/-1∗X2SD601ARAB
Q906VS2SD601AR/-1∗X2SD601ARAB
Q907VS2SD601AR/-1∗X2SD601ARAB
Q908VS2SB709AR/-1∗X2SB709ARAB
Q910VS2SB709AR/-1∗X2SB709ARAB
Q2060VS2SD601AR/-1∗X2SD601ARAB
Q2201VS2SD601AR/-1∗X2SD601ARAB
Q2211VS2SD601AR/-1∗X2SD601ARAB
DIODES
D52RH-EX0676GEZZ∗XZener Diode, 32VAB
D103RH-DX0441CEZZ∗XDiodeAB
D361VHD1SS119//-1∗X1SS119AA
D362VHD1SS119//-1∗X1SS119AA
D410RH-EX0611GEZZ∗XZener Diode, 5.1VAB
D411RH-EX0611GEZZ∗XZener Diode, 5.1VAB
D412RH-EX0614GEZZ∗XZener Diode, 5.6VAB
D413RH-EX0614GEZZ∗XZener Diode, 5.6VAB
D414RH-EX0614GEZZ∗XZener Diode, 5.6VAB
D454RH-EX0628GEZZ∗XZener Diode, 8.2VAB
D455VHD1SS119//-1∗X1SS119AA
D501 RH-DX0302CEZZ∗XDiode AB
D502 VHD1SS119//-1∗ X 1SS119 AA
D510RH-DX0441CEZZ∗XDiodeAB
åD606RH-DX0302CEZZ∗XDiodeAB
D607RH-DX0471CEZZ∗XDiodeAB
D621RH-EX0631GEZZ∗XZener Diode, 9.1VAB
åD622RH-DX0131CEZZ∗XDiodeAB
IC602 VHIBA15218F2E* X BA15218 AB
IC1401 VHITC90A53F-1* X C90A53 AP
Q471 VS2SD601AR/-1* X 2SD601AR AB
Q771 VS2SA1091-O1A+ X SA1091 AC
Q770 VS2SC3333//-1+ X SC3333 AB
Q472 VS2SD601AR/-1* X 2SD601AR AB
Q473 VS2SD601AR/-1* X 2SD601AR AB
PWB-A: DUNTKB567WEA0
MAIN UNIT
TUNER
ASSEMBLY BUT NOT INDEPENDENTLY.
NOTE:THE PARTS HERES SHOWN ARE SUPPLIED AS AN
TU51 VTUVTST5UF740 X Tuner AR
Q673 VS2SD1830// 1E X SD1830//1 AD
Q672 VS2SA1266-Y-1
+ X 2SA1266-Y AB
D605 RH-DX0255CEZZ X 2SD601AR AD
