Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
32
32R-S480
CR32S48
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
'åV101 VB80LJF3016~S X CRT (I.T.C) CT
or
VB80ECK272X1E X CRT (I.T.C)
or
VB80ECK272X2E X CRT (I.T.C)
or
VB80AKB50X/~S X CRT (I.T.C)
or
VB80LJF30X/~S X CRT (DY601: H0108ME)
'åDY601 RCiLH0108MEZZ X DY (V101: A80LJF30X) AZ
å L703 RCiLG0051MEZZ X Degaussing Coil AV
or (PR701: P0072CE)
RCiLG0118GJZZ Degaussing Coil
or (PR701: P0072CE)
RCiLG0034MEZZ Degaussing Coil
or (PR701: P0059CE)
RCiLG0028MEZZ Degaussing Coil
(PR701: P0059CE)
LHLDW0102GJKZ X ADG Coil Holder AC
MSPRT0002MEZZ X Spring AF
QCNW-0162GJZZ X Connecting Cord (PU) AG
å QEARC3102MEZZ X Grounding Strap AG
PWB-A DUNTKA526WEB3 – MAIN Unit (32R-S480) —
PWB-A DUNTKA526WEB8 – MAIN Unit (CR32S48) —
PWB-B DUNTKA527WEA2 – CRT Unit —
PWB-C DUNTKA602WEA0 – AV Unit —
PWB-R DUNTKA533WEA0 – P-IN-P Unit —
PWB-S DUNTKA070WEV3 – MTS MODULE Unit —
★ MARQUE: SECTION LIVRAISON DES PIECES DERECHANGE
' MARQUE: PIECES RELATIVE AUX RAYONS X
LISTE DES PIECES
CHANGE DES PIECES
Les pi`eces de rechange qui pr élelesentent ces caract éleristiques sp
éleciales de s élecurit éle, sont identifi élees dans ce manuel : les pi`eces
élelectriques qui pr élesentent ces particularit éles, sont rep éler élee
par la marque å et sont hachur élees dans les listes de pi`eces et dans
les diagrammes sch élematiques.
La substitution d'une pi`ece de rechange par une autre qui ne pr éLesente
pas les m éoemes caract éLeristiques de s élecurit éle que la pi`ece
recommand élee parl'usine et dans ce manuel de service, peut provoquer
une éLelectrocution, un incendie ou toutautre sinistre.
"COMMENT COMMANDER LES PIECES DE RECHANGE"
Pour que votre commande soit rapidement et correctement remplie,
veuillez fournir les renseignements suivants.
1. NUMERO DU MODELE 2. NO. DE REF
3. NO. DE PIECE 4. DESCRIPTION
in CANADA: Contact SHARP Electronics of Canada Limited
Phone (416) 890-2100
Ref. No. Part No. ★ Description Code
PWB-A: DUNTKA526WEB3(32R-S480)
PWB-A: DUNTKA526WEB8(CR32S48)
MAIN UNIT
PICTURE TUBE
★ MARK: SPARE PARTS-DELIVERY SECTION
' MARK: X-RAY RELATED PARTS
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics iden-
tified in this manual ; electrical components having such features are
identified by å and shaded areas in the Replacement Parts Lists and
Schematic Diagrams. The use of a substitute replacement part which
does no have the same safety characteristic as the factory recom-
mended replacement parts shown in this service manual may create
shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the fol-
lowing informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order. For
location of SHARP Parts Distributor, Please call Toll-Free; 1-
800-BE-SHARP
Ref. No. Part No. ★ Description Code
TUNER
NOTE: THE PARTS HERES SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
å TU51 VTUVTST5UF770 J Tuner AZ
INTEGRATED CIRCUITS
å IC201 RH-iX3395CEN2 J TB1252CN AY
å IC361 VHiAN5276//-1 J AN5276 AR
å IC501 VHiTA8427K/-1 J TA8427K AL
IC680 VHiKiA358P+-1 X KIA358P AF
or
VHiiR9358//-1
or
VHiUPC358C/-1
å IC701 VHiTEA1507/-1 J TEA1507P/N1 AL
å IC702 RH-FX0008GEZZ J PC123FY8 AE
å IC703 VHiSE125N//-1 X SE125N AK
IC751 VHiSTV8164+-1 X I.C. AM
IC2001 RH-iX3515CEN2 X TMPA8700CPF-3F AT
IC2040 VHiKiA7045A-1 J KA7045AP AE
or
VHiKiA7045P-1
IC2101 VHiM24C16B/-1 J M24C16-BN6 AG
TRANSISTORS
Q201 VS2SC2735//1E J 2SC2735 AC
Q205 VS2SC1623L61E J 2SC1623L6 AB
or
VS2SD601AR/-1
Q206 VS2SC1623L61E J 2SC1623L6 AB
or
VS2SD601AR/-1
Q361 VS2SA812-M51E J 2SA812-M5 AC
or
VS2SB709AR/-1
Q402 VS2SA812-M51E J 2SA812-M5 AC
or
VS2SB709AR/-1
Q405 VS2SC1623L61E J 2SC1623L6 AB
or
VS2SD601AR/-1
To Next Page
