Trademarks
• The terms HDMI and HDMI High-Defi nition Multimedia Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing LLC in the United States and other countries.
• TruSurround HD, SRS and the symbol are trademarks of SRS Labs, Inc.
TruSurround HD technology is incorporated under license from SRS Labs, Inc.
• SRS TruSurround HD™ creates an immersive, feature-rich surround sound experience from two speakers, complete with
rich bass, high frequency detail and clear dialog.
• Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
• DivX
®
, DivX Certifi ed
®
and associated logos are trademarks of DivX, LLC and are used under license.
• This DivX Certifi ed
®
device has passed rigorous testing to ensure it plays DivX
®
video.
• To play purchased DivX movies, fi rst register your device at vod.divx.com. Find your registration code in the DivX VOD
section of your device setup menu.
• MHL, the MHL Logo, and Mobile High-Defi nition Link are trademarks or registered trademarks of MHL, LLC in the United
States and other countries.
• The Wi-Fi CERTIFIED™ Logo is a certifi cation mark of Wi-Fi Alliance
®
.
• YouTube and the YouTube logo are trademarks of Google Inc.
• LC
_
LCFONT
+
and LC logo mark are registered trademarks of SHARP Corporation. This product
is embedded with LC Font technology, which was developed by SHARP Corporation for clearly displaying easy-to-read
characters on an LCD screen. However, other non-LCD fonts are used for displaying some screen pages.
Quick Reference
Attaching the stand
• Before attaching (or detaching) the stand, unplug the AC cord from the AC outlet.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it from being damaged.
1
Confi rm the screws supplied with the TV.
(Six long screws and four short screws)
2
Insert the support angle into the stand base slot holes. (
1
)
• Please make sure left support angle into the left stand base and right support angle into the right stand base
(left side part engraved “L”, right side part engraved “R”).
Quick Reference
3
Push the support angle follow the direction of the arrow mark on the stand base.
Push
Push the support angle follow
the direction of the arrow mark
4
For easily, user can use polystyrene foam as a jig to hold the stand base when fi xing by using the long
screws. (
2
)
2
Example for left side
2
5
Insert the stand into the openings on the bottom of the TV. (
3
)
6
Insert and tighten four short screws into the holes on the rear of the TV. (
4
)
Soft cushion
OUTPU
T
DC5
V
1
.5A
H
D
MI
4
HDMI
5
U
SB
2
DC5V 0
.5A
AU
DI
O IN
D
IGITAL
AUDIO
OUTPU
T
ANALOGUE
RGB (PC
)
ARC
PC
H
DMI 1
INPUT 6
INPUT 7
AUDIO OUT
R
- AUDIO - L
R - AUDIO - L
R
- AUD
I
O -
L
V
ID
E
O/
Y
P
B
(C
B
)
P
R
(C
R
)
COMPO
NENT/AV
INPUT
VIDEO
RS-232C IOIOI
US
B
1
D
C
5V 1.5A
(DC5V 90
0
mA)
AUD
I
O
(L
/
R)
C
.I.
M
HL
HDMI 2
HDM
I 3
OUTPUT
3
4
NOTE
• To detach the stand, perform the steps in reverse order.
• Refer “Building the Work Table” in carton box to assemble the TV.
CAUTION
• Do not attach or detach the stand without holding it.
Doing so can cause the stand to fall, resulting in serious personal injuries as well as damage to the stand.
• The illustrations used throughout this manual are based on LC-60LE660X.
Polystyrene foam
