Sharp CK32S4 User Manual

32K-S400, CK32S40
36K-S400, CK36S40
H
G
F
E
D
C
B
A
123456789101112
32K-S400, CK32S40
36K-S400, CK36S40
33 34
32K-S400, CK32S40
çå V101 VB80LJF3015*S M Picture Tube DD
or
VB80JUA061X*S
or
VB80JF30X15/
çå DY601 RCiLH0108MEZZ M Defrection Yoke
or
RCiLH0109MEZZ
or
RCiLH0104MEZZ
V101 DY601 C610 R621
Combi- A80LJF30X H0108ME 9100p(1.6kV) 1.2(3W)
nation M80JUA061X H0109ME 0.01(1.6kV) 1.5(3W)
H0104ME 0.01(1.6kV) 1.5(3W)
A80LJF30X15 — 9100p(1.6kV) 1.2(3W)
å L703 RCiLG0034MEZZ M Degaussing Coil AV
or
RCiLG0028MEZZ AZ
MSPRT0002MEZZ M Spring for CRT AA
QEARC3102MEZZ M Ground-Part AH
36K-S400, CK36S40
çå V101 VB90AHH50X06S M Picture Tube (with D.Y)
or
VB90AEJ15X09S
V101 R621
Combi- A90AHH50X06 2.7(3W)
nation A90AEJ15X09 2.2(3W)
å L703 RCiLG0035MEZZ M Degaussing Coil AW
or
RCiLG0027MEZZ AZ
MSPRT0002MEZZ M Spring for CRT AA
QEARC3502MEZZ M Ground-Part AH
Ref. No. Part No. ★ Description Code
Ref. No. Part No. ★ Description Code
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
MARK★: SPARE PARTS-DELIVERY SECTION
▲ MARK : X- RAY RELATED PARTS
LISTE DES PIECES
CHANGE DES PIECES
Les pi`eces de rechange qui pr élelesentent ces caract éleristiques
sp éleciales de s élecurit éle, sont identifi élees dans ce manuel : les
pi`eces élelectriques qui pr élesentent ces particularit éles, sont rep
éler élee par la marque å et sont hachur élees dans les listes de
pi`eces et dans les diagrammes sch élematiques.
La substitution d'une pi`ece de rechange par une autre qui ne pr
éLesente pas les m éoemes caract éLeristiques de s élecurit éle que
la pi`ece recommand élee parl'usine et dans ce manuel de service,
peut provoquer une éLelectrocution, un incendie ou toutautre sinistre.
"COMMENT COMMANDER LES PIECES DE RECHANGE"
Pour que votre commande soit rapidement et correctement remplie,
veuillez fournir les renseignements suivants.
1. NUMERO DU MODELE 2. NO. DE REF
3. NO. DE PIECE 4. DESCRIPTION
in CANADA: Contact SHARP Electronics of Conada Limited
Phone (416) 890-2100
★MARQUE: SECTION LIVRAISON DES PIECES DE RECHANGE
▲ MARQUE : PIECES RELATIVE AUX RAYONS X
PICTURE TUBE
PWB-A DUNTK9513WEK0 – MAIN Unit —
(32K-S400, CK32S40)
PWB-A DUNTK9513WEK1 – MAIN Unit —
(36K-S400, CK36S40)
PWB-B DUNTK9303WEK3 – CRT Unit —
(32K-S400, CK32S40)
PWB-B DUNTK9303WEK4 – CRT Unit —
(36K-S400, CK36S40)
PWB-F DUNTK9514WEK0 – CONTROL Unit —
PWB-R DUNTK9511WEK1 – P-IN-P Unit —
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
TUNER
NOTE: THE PARTS HERES SHOWN ARE SUPPLIED AS AN
ASSEMBLY NOT INDEPENEDENTLY.
å TU51 VTU115B8025AM M Tuner
INTEGRATED CIRCUITS
IC101 VHiKA78S05P-1 J KIA78S05P AD
çå IC201 RH-iX2933CEZZ J TA1268N AX
å IC361 RH-iX1135CEZZ J LA4261 AH
IC470 VHiM52055FP-1 J M52055FP AH
å IC501 VHiTA8427K/-1 J TA8427K AL
or
RH-iX1224CEZZ AH
IC671 VHiUPC358C/-1 J UPC358C AD
çå IC701 VHiSTRF65161E J STR-F6516
å IC702 RH-FX0002GEZZ J PS2501-1 AD
å IC703 VHiSE125N//-1 J SE125N
(32K-S400, CK32S40)
å IC703 VHiSE135N//-1 J SE135N
(36K-S400, CK36S40)
å IC750 VHiKA7812Pi-1 R KIA7812PI AE
å IC751 VHiKA7809Pi-1 R KIA7809PI AE
IC951 VHiMM1113XF1E J MM1113XFBE AE
IC2001 RH-iX3088CEN2 J IC AU
IC2040 VHiKiA7045P-1 J KIA7045P AD
IC2101 RH-iX2447CEN1 J ST24C01B6 AL
or
RH-iX2448CEN1
IC3001 VHiCXA2074Q-1 J CXA2074Q AS
IC3201 VHiAN5285K/-1 J AN5285K AP
TRANSISTORS
You can substitute "2SD601AR" for "2SC2462".
Q201 VS2SC2735//1E J 2SC2735 AC
Q301 VS2SD601AR/-1 J 2SD601 AC
Q360 VS2SD601AR/-1 J 2SD601 AC
Q401 VS2SD601AR/-1 J 2SD601 AC
Q402 VS2SB709AR/-1 J 2SB709 AC
Q403 VS2SD601AR/-1 J 2SD601 AC
Q421 VS2SB709AR/-1 J 2SB709 AC
Q451 VS2SD601AR/-1 J 2SD601 AC
Q601 VS2SC2482//-1 J 2SC2482 AD
å Q602 VS2SD2500//2E J 2SD2500 AT
(32K-S400, CK32S40)
å Q602 VS2SC5150//2E J 2SC5150
(36K-S400, CK36S40)
Q672 VS2SA1266-Y-1 J 2SA1266(Y) AA
Q673 VS2SD2045//-1 J 2SD2045 AL
Q751 VS2SC3198-Y-1 J 2SC3198(Y) AA
Q821 VS2SD601AR/-1 J 2SD601 AC
Q822 VS2SD601AR/-1 J 2SD601 AC
Q901 VS2SD601AR/-1 J 2SD601 AC
Q902 VS2SD601AR/-1 J 2SD601 AC
Q903 VS2SD601AR/-1 J 2SD601 AC
Q904 VS2SD601AR/-1 J 2SD601 AC
Q921 VS2SD601AR/-1 J 2SD601 AC
Q922 VS2SD601AR/-1 J 2SD601 AC
Q923 VS2SD601AR/-1 J 2SD601 AC
Q924 VS2SD601AR/-1 J 2SD601 AC
Q1601 VS2SD601AR/-1 J 2SD601 AC
Q1602 VS2SB709AR/-1 J 2SB709 AC
Q2060 VS2SD601AR/-1 J 2SD601 AC
Q2201 VS2SD601AR/-1 J 2SD601 AC
Q2211 VS2SD601AR/-1 J 2SD601 AC
DIODES
D51 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D52 RH-EX0676GEZZ J Zener Diode, 32V AA
D103 VHD1SS119//-1 J Diode AB
D401 VHD1SS119//-1 J Diode AB
D402 RH-EX0723GEZZ J Zener Diode, 3.3V AB
or
RH-EX0092CEZZ
D403 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D404 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D405 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D454 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D455 VHD1SS119//-1 J Diode AB
D481 VHD1SS119//-1 J Diode AB
D482 VHD1SS119//-1 J Diode AB
D483 VHD1SS119//-1 J Diode AB
D484 VHD1SS119//-1 J Diode AB
å D501 RH-DX0302CEZZ J Diode AC
D510 RH-DX0441CEZZ J Diode AC
D511 RH-EX0654CEZZ J Zener Diode, 75V AD
D602 VHD1SS119//-1 J Diode AB
å D605 RH-DX0255CEZZ J Diode AC
D621 RH-EX0631GEZZ J Zener Diode, 9.1V AA
D622 RH-DX0131CEZZ J Diode AC
D631 RH-EX0630GEZZ J Zener Diode, 9.1V AA
çå D651 RH-DX0073CEZZ J Diode AD
çå D652 RH-EX0641GEZZ J Zener Diode, 12V AA
çå D653 VHD1SS119//-1 J Diode (32K-S400, CK32S40) AB
çå D654 VHD1SS119//-1 J Diode (32K-S400, CK32S40) AB
D671 RH-EX0664GEZZ J Zener Diode, 24V AA
D672 VHD1SS119//-1 J Diode AB
å D673 RH-DX0229CEZZ J Diode AF
or
RH-DX0444CEZZ
D674 VHD1SS119//-1 J Diode AB
D705 VHD1SS82///1A J Diode AC
D706 RH-DX0066GEZZ J Diode AB
D707 VHD1SS82///1A J Diode AC
D708 RH-DX0066GEZZ J Diode AB
å D709 RH-DX0229CEZZ J Diode AF
å D712 RH-DX0407CEZZ J Diode AD
å D713 RH-DX0259CEZZ J Diode AH
D715 RH-EX0354GEZZ J Zener Diode, 3.6V AA
D716 VHD1SS119//-1 J Diode AB
D717 RH-EX0650GEZZ J Zener Diode, 16V AB
å D725 RH-DX0407CEZZ J Diode AD
PWB-A: DUNTK9513WEK0(32K-S400, CK32S40)
PWB-A: DUNTK9513WEK1(36K-S400, CK36S40)
MAIN UNIT
