Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
42
32K-S400,CK32S40
36K-S400,CK36S40
å R864 VRS-VV3DB273J J 27k 2W M-Ox. AA
R868 VRD-RM2HD224J J 220k 1/2W Carbon AA
R870 VRD-RA2BE471J J 470 1/8W Carbon AA
R871 VRD-RA2BE471J J 470 1/8W Carbon AA
R872 VRD-RA2BE471J J 470 1/8W Carbon AA
R873 VRD-RA2BE220J J 22 1/8W Carbon AA
R874 VRD-RA2BE220J J 22 1/8W Carbon AA
R875 VRD-RA2BE220J J 22 1/8W Carbon AA
R876 VRD-RA2BE121J J 120 1/8W Carbon AA
R877 VRD-RA2BE121J J 120 1/8W Carbon AA
R878 VRD-RA2BE121J J 120 1/8W Carbon AA
R880 VRC-MA2HG332K J 3.3k 1/2W Solid AA
R881 VRC-MA2HG332K J 3.3k 1/2W Solid AA
R882 VRC-MA2HG332K J 3.3k 1/2W Solid AA
R883 VRD-RA2BE221J J 220 1/8W Carbon AA
R884 VRD-RA2BE221J J 220 1/8W Carbon AA
R885 VRD-RA2BE221J J 220 1/8W Carbon AA
R886 VRD-RA2BE471J J 470 1/8W Carbon AA
R887 VRD-RA2BE471J J 470 1/8W Carbon AA
R888 VRD-RA2BE471J J 470 1/8W Carbon AA
R891 VRD-RA2BE561J J 560 1/8W Carbon AA
R892 VRD-RA2BE331J J 330 1/8W Carbon AA
R894 VRD-RA2BE152J J 1.5k 1/8W Carbon AA
R895 VRD-RA2EE561J J 560 1/4W Carbon AA
MISCELLANEOUS PARTS
P860 QPLGN0461CEZZ J Plug, 4-pin(YBN) AB
P880 QPLGN0561CEZZ J Plug, 5-pin(GBN) AB
SC801 QSOCV0937CEZZ J Socket (32K-S400, CK32S40) AF
or
QSOCV0938CEZZ
SC801 QSOCV1011CEZZ J Socket (36K-S400, CK36S40)
PWB-B: DUNTK9303WEK3(32K-S400, CK32S40)
PWB-B: DUNTK9303WEK4(36K-S400, CK36S40)
CRT UNIT (Continued)
CAPACITOR
[EL.··· Electrolytic]
C4001 VCEA0A1HW475M J 4.7 50V EL. AB
RESISTORS
R4001 VRD-RA2BE103J J 10k 1/8W Carbon AA
R4003 VRD-RA2BE273J J 27k 1/8W Carbon AA
R4004 VRD-RA2BE563J J 56k 1/8W Carbon AA
R4005 VRD-RA2BE331J J 330 1/8W Carbon AA
R4006 VRD-RA2BE563J J 56k 1/8W Carbon AA
R4007 VRD-RA2BE123J J 12k 1/8W Carbon AA
R4008 VRD-RA2EE750J J 75 1/4W Carbon AA
R4009 VRD-RA2BE153J J 15k 1/8W Carbon AA
R4010 VRD-RA2BE272J J 2.7k 1/8W Carbon AA
SWITCHES
S4001 QSW-K0079GEZZ J Power AB
S4002 QSW-K0079GEZZ J CH-up AB
S4003 QSW-K0079GEZZ J CH-down AB
S4004 QSW-K0079GEZZ J VOL-up AB
S4005 QSW-K0079GEZZ J VOL-down AB
MISCELLANEOUS PARTS
J4001 QJAKE0179CEZZ M Jack, Audio-In(L)
J4002 QJAKE0180CEZZ M Jack, Audio-In(R)
J4003 QJAKE0181CEZZ M Jack, Video-In
P4001 QPLGN0461CEZZ J Plug, 4-pin(YR) AB
P4003 QPLGN0661CEZZ J Plug, 6-pin(EJ) AD
RMC4001 RRMCU0230CEZZ M R/C Receiver
or
RRMCU0231CEZZ
QCNW-0176MEZZ M Connecting Cord
QCNW-0179MEZZ M Connecting Cord
PWB-F: DUNTK9514WEK0
CONTROL UNIT
