Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
38
CX34K3
S1002 QSW-K0077GEZZ R CH-Down AB
or
QSW-K0079GEZZ
S1003 QSW-K0077GEZZ R VOL-Up AB
or
QSW-K0079GEZZ
S1004 QSW-K0077GEZZ R VOL-Down AB
or
QSW-K0079GEZZ
S1005 QSW-K0077GEZZ R Picture/Preset AB
or
QSW-K0079GEZZ
MISCELLANEOUS PARTS
å F701 QFS-C3229CEZZ R Fuse T3.15A 250V AD
FB306 RBLN-0037CEZZ R Ferrite Bead AB
FB501 RBLN-0037CEZZ R Ferrite Bead AB
FB502 RBLN-0037CEZZ R Ferrite Bead AB
FB602 RBLN-0037CEZZ R Ferrite Bead AB
FB701 RBLN-0037CEZZ R Ferrite Bead AB
FB702 RBLN-0037CEZZ R Ferrite Bead AB
FB751 RBLN-0037CEZZ R Ferrite Bead AB
FB752 RBLN-0037CEZZ R Ferrite Bead AB
FH701 QFSHD1014CEZZ R Fuse Holder AC
FH702 QFSHD1013CEZZ R Fuse Holder AC
J402 QJAKE0158CEZZ R Rear Jack, Video AF
J403 QJAKE0159CEZZ R Rear Jack, Audio (L) AF
J405 QJAKH0011AJZZ R Front AV Jack AK
P302 QPLGN0241CEZZ R Plug, 2-pin (S) AA
P303 QPLGN0741CEZZ R Plug, 7-pin (HP) AB
P502 QPLGN0660CEZZ R Plug, 6-pin (F) AC
P602 QPLGN0641CEZZ R Plug, 6-pin (H) AB
P701 QPLGN0260CEZZ R Plug, 2-pin (G) AC
P712 QPLGN0269GEZZ R Plug, 2-pin (A) AB
P1001 QPLGN0541CEZZ R Plug, 5-pin (K) AB
P1002 QPLGN0541CEZZ R Plug, 5-pin (BC) AB
RMC1001 RRMCU0235CEZZ R R/C Receiver AK
JA160 VRD-RA2BE101J R 100 1/8W Carbon AB
TP201 QLUGP0102PEZZ J Lug, Test Point AA
RDA300PRDAR0142PEFW J Heat Sink, for IC301 AD
RDA601PRDAR0224PEFW J Heat Sink, for Q602 AF
RDA700PRDAR0260PEFW J Heat Sink, for IC701 AH
RDA501PRDAR0298PEFW J Heat Sink, for IC501 AF
LHLDP1066PE00 J Holder AC
LX-BZ0007PEFD J Screw AA
LX-BZ0086TAFD R Screw AA
LX-BZ3049GEFD R Screw AA
LX-BZ3100CEFD R Screw AA
LX-TZ3004CEFD R Screw AA
PWB-B DUNTK9990WEV0
CRT UNIT
TRANSISTORS
Q870 VSBF422////-1 R BF422 AC
Q871 VSBF422////-1 R BF422 AC
Q872 VSBF422////-1 R BF422 AC
Q883 VSBF421////-1 R BF421 AC
Q885 VSBF421////-1 R BF421 AC
Q887 VSBF421////-1 R BF421 AC
DIODES
D811 RH-DX0475CEZZ R Diode AB
D812 RH-DX0475CEZZ R Diode AB
D880 RH-DX0475CEZZ R Diode AB
D881 RH-DX0475CEZZ R Diode AB
D882 RH-DX0475CEZZ R Diode AB
D883 VHD1SS82///1A R Diode AC
D884 VHD1SS82///1A R Diode AC
D885 VHD1SS82///1A R Diode AC
D886 VHD1SS82///1A R Diode AC
D887 VHD1SS82///1A R Diode AC
D888 VHD1SS82///1A R Diode AC
D890 RH-DX0627GEZZ R Zender Diode
CAPACITORS
C871 VCKYPA1HB471K R 470p 50V Ceramic AA
C872 VCKYPA1HB471K R 470p 50V Ceramic AA
C873 VCKYPA1HB471K R 470p 50V Ceramic AA
C875 VCKYPA2HB102K R 1000p 500V Ceramic AA
C876 RC-KZ0150CEZZ R 1000p 3kV Ceramic AB
C878 VCEAGA2EW106M R 10 250V Electrolytic AC
C880 VCKYPA1HB471K R 470p 50V Ceramic AA
C881 VCKYPA1HB471K R 470p 50V Ceramic AA
C882 VCKYPA1HB471K R 470p 50V Ceramic AA
RESISTORS
R879 VRD-RA2BE471J R 470 1/8W Carbon AA
R880 VRD-RA2BE471J R 470 1/8W Carbon AA
R881 VRD-RA2BE471J R 470 1/8W Carbon AA
R882 VRS-VV3DB153J R 15k 2W Metal Oxide AA
R883 VRD-RM2HD272J R 2.7k 1/2W Carbon AA
R884 VRS-VV3DB153J R 15k 2W Metal Oxide AA
R885 VRD-RM2HD272J R 2.7k 1/2W Carbon AA
R886 VRS-VV3DB153J R 15k 2W Metal Oxide AA
R887 VRD-RM2HD272J R 2.7k 1/2W Carbon AA
R888 VRD-RA2BE471J R 470 1/8W Carbon AA
R892 VRD-RA2BE102J R 1.0k 1/8W Carbon AA
R893 VRD-RA2BE102J R 1.0k 1/8W Carbon AA
R894 VRD-RA2BE102J R 1.0k 1/8W Carbon AA
R898 VRD-RA2BE471J R 470 1/8W Carbon AA
R899 VRD-RA2BE471J R 470 1/8W Carbon AA
MISCELLANEOUS PARTS
P851 QPLGN0641CEZZ R Plug, 6-pin (H) AB
P882 QPLGN0541CEZZ R Plug, 5-pin (K) AB
å SC881 QSOCV0842CEZZ R CRT Socket AH
PWB-C DUNTK9989WEV0
HEADPHONE UNIT
RESISTORS
RJ1 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ7 VRN-MD2AL000J R 0 1/10W Metal Film AA
RJ8 VRN-MD2AL000J R 0 1/10W Metal Film AA
R354 VRN-MD2AL471J R 470 1/10W Metal Film AA
R355 VRN-MD2AL471J R 470 1/10W Metal Film AA
MISCELLANEOUS PARTS
J351 QJAKJ0047CEZZ R Headphone Jack AD
P352 QPLGN0441CEZZ R Plug, 4-pin AB
