Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
114
LC-22AD1E
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
★ MARK: SPARE PARTS-DELIVERY SECTION
NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
Ref. No. Part No. ★ Description Code
PRINTED WIRING BOARD ASSEMBLIES
(
NOT REPLACEMENT ITEM
)
LCD PANEL
DUNTKB973FE04 – INVERTER Unit —
DUNTKC160DE01 – AV Unit —
DUNTKC162DE01 – R/C, LED Unit —
DUNTKC163DE01 – OPERATION Unit —
DUNTKC164DE01 – EXT-SP TERMINAL Unit —
DUNTKC165DE01 – SP-JACK Unit —
DUNTKC166FE01 – MAIN Unit —
RUNTKA060WJZZ J EU-DIGITAL Unit CR
B2SX4052BT J 1BIT-AMP Unit BL
(Unit Replacement Item)
RLCDTA021WJZZ J 22" LCD panel unit EM
DUNTKB973FE04
INVERTER Unit
TRANSISTORS
Q6551 VS2SC5886++-1Y J 2SC5886 AE
Q6552 VS2SC5886++-1Y J 2SC5886 AE
Q6553 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q6554 VS2SC5886++-1Y J 2SC5886 AE
Q6555 VS2SC5886++-1Y J 2SC5886 AE
Q6556 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q6557 VS2SC5886++-1Y J 2SC5886 AE
Q6558 VS2SC5886++-1Y J 2SC5886 AE
Q6559 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q6560 VS2SC5886++-1Y J 2SC5886 AE
Q6561 VS2SC5886++-1Y J 2SC5886 AE
Q6562 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q6563 VS2SC2412KQ-1Y J 2SC2412KQ AA
Q6564 VS2SC2412KQ-1Y J 2SC2412KQ AA
Q6565 VS2SC2412KQ-1Y J 2SC2412KQ AA
Q6566 VS2SC2412KQ-1Y J 2SC2412KQ AA
Q6567 VS2SC2412KQ-1Y J 2SC2412KQ AA
Q6568 VS2SC2412KQ-1Y J 2SC2412KQ AA
Q6569 VS2SC2412KQ-1Y J 2SC2412KQ AA
Q6570 VS2SC2412KQ-1Y J 2SC2412KQ AA
DIODES
D6551 VHDHSU119//-1Y J Diode AB
D6552 VHDHSU119//-1Y J Diode AB
D6553 VHDHSU119//-1Y J Diode AB
D6554 VHDHSU119//-1Y J Diode AB
COILS
L6552 RCiLPA034WJZZ J Coil AD
L6554 RCiLPA034WJZZ J Coil AD
L6556 RCiLPA034WJZZ J Coil AD
L6558 RCiLPA034WJZZ J Coil AD
TRANSFORMERS
å T6551 RTRNZA038WJZZQ J Transformer AP
å T6552 RTRNZA038WJZZQ J Transformer AP
å T6553 RTRNZA038WJZZQ J Transformer AP
å T6554 RTRNZA038WJZZQ J Transformer AP
CAPACITORS
C6551 RC-FZA108WJZZ J 0.12 250V Film AD
C6555 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6556 VCKYCY1EB103KY J 0.01 25V Ceramic AA
C6558 RC-EZA216WJZZ J 1000 16V Electrolytic AD
C6560 RC-FZA108WJZZ J 0.12 250V Film AD
C6563 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6564 VCKYCY1EB103KY J 0.01 25V Ceramic AA
C6566 RC-EZA216WJZZ J 1000 16V Electrolytic AD
C6567 RC-FZA108WJZZ J 0.12 250V Film AD
C6571 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6572 VCKYCY1EB103KY J 0.01 25V Ceramic AA
C6574 RC-EZA216WJZZ J 1000 16V Electrolytic AD
C6575 RC-FZA108WJZZ J 0.12 250V Film AD
C6579 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6580 VCKYCY1EB103KY J 0.01 25V Ceramic AA
C6582 RC-EZA216WJZZ J 1000 16V Electrolytic AD
RESISTORS
R6551 VRS-TW2ED182JY J 1.8k 1/4W Metal Oxide AA
R6553 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R6554 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6555 VRS-TW2ED182JY J 1.8k 1/4W Metal Oxide AA
R6557 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R6558 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6559 VRS-TW2ED182JY J 1.8k 1/4W Metal Oxide AA
R6561 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R6562 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6563 VRS-TW2ED182JY J 1.8k 1/4W Metal Oxide AA
To Next Page
