Sharp LC-26SB25E Service Manual

LC-26SB25E/S/RU, LC-32SB25E/S/RU, LC-42SB55E/S/RU
106
CHAPTER 9. PARTS GUIDE
[1] SPARE PARTS LIST
Model: LC-42SB55E(CMO)
Item Code number Description Sharp C/N
Mechanical Parts
70 705TP833007 KEY PAD ASSY 9JR7050000011
30 705TP834027 BEZEL ASSY 9JR7050000016
40 705TP834028 REAR COVER ASSY 9JR7050000017
50 705TP837010 BASE ASSY 9JR7050000020
60 705TP837011 BASE STAND ASSY 9JR7050000021
1185 078T 499902 1M SPEAKER 6OHM 10W 156mmx30mm 9JR7800000001
1186 078T 499902 1M SPEAKER 6OHM 10W 156mmx30mm 9JR7800000001
Accessory
136 705TZ841031 DFU ASSY 9JR7050000024
705TZ841028 DFU ASSY 9JR7050000023
1172 089T404A18NHT2 POWER CORD 1.8M 4L4L-040-00K 9JR8900000003
1176 098TRABD5NESHC REMOTE CONTROL RL57S 9JR9800000002
Packing
451 705TZ8CS006 CUSHION Assy 9JR7050000025
450 P44TN015843 1A CARTON 9JR4400000014
miscellanea
100 0Q1T 940 25 47 CR3 Screw dia.4 x25 9JR0100000021
101 0M1T1140 6120 SCREW 4*6MM 9JR0100000003
102 0Q1T 940 12 47 CR3 T4X12 SCREW 9JR0100000008
103 0M1T1730 8106 CR3 SCREW 9JR0100000019
104 0Q1T 930 8 47 CR3 SCREW 9JR0100000007
105 0Q1T1040 8120 SCREW 9JR0100000010
106 0M1T6022500 SCREW 9JR0100000005
108 0M1T 330 6 47 CR3 SCREW 9JR0100000001
109 0M1T 940 16 47 CR3 SCREW M4X6 9JR0100000002
126 P40TNV0084325B 1RATING LABEL 9JR4000000029
127 P40TA00081328A FAMILY SHEET- SERVICE 9JR4000000004
130 P40TN00084358A CARTON LABEL 9JR4000000028
137 P40TN00084342B LABEL_SIDE_IO 9JR4000000021
143 P45T 48005 1A P.E. BAG(100 X 70) 9JR4500000003
144 P41TN025843 1C QSG-1 (Western & North Europe) 9JR4100000008
145 P41TN026843 1B QSG-2 (Eastern Europe & Russia) 9JR4100000009
455 P45T 46023 PE BAG(1200X1000x0.72mm) 9JR4500000008
503 P40TD000813 9A family sheet 9JR4000000005
506 P40TD00081311A FAMILY SHEET 9JR4000000006
8390 095T8014 4F924 HARNESS 4P-4P 700mm 75261 9JR9500000008
8391 095T8014 5F911 HARNESS 5P-5P 350mm 75260 9JR9500000011
8600 095T8013 2F924 HARNESS 2P-FAST 440mm 75262 9JR9500000002
8601 095T8013 3F907 HARNESS 3P-FAST 1030mm 75263 9JR9500000005
8750 095T8018 51929 FP HARNESS 51P-20*2P 310mm 75229 9JR9500000022
8903 095T801413F909 HARNESS 13P-12P 770mm 75258 9JR9500000016
8905 095T801414F921 HARNESS 14P-13P 150mm 75257 9JR9500000017
LCD panel
1050 750TVMT0H1741N000P Panel V420H1-L07 C3 TW CMO 9JR7500000007
1050 750TVMT0H1742N000P Panel V420H1-L07 C3 NB CMO 9JR7500000008
1050 750TVMT0H1743N000P PANEL V420H1-L07 C3 NH CMO 9JR7500000009
PCB assy
1054 ADTV82428PA3 POWER PCB ASSY 9JR9900000001
1053 CBPF82MBPL Main Pcb Assy SHARP 42"-CMO 9JR9900000006
1056 IRPF8PB7 IR PCB ASSY 9JR9900000009
1057 KEPF8PB2 KEY BOARD 9JR9900000010
Main PCB
1053 CBPF82MBPL Main Pcb Assy SHARP 42"-CMO
1261 TUPF8PD1 TUNER+EEPROM ASSY 9JR9900000014
1262 705TP856090 NOR FLASH ASSY (U390) 9JR7050000031
1302 705TP856089 Serial IIC EEPROM ASSY (CMO-Panasonic) 9JR7050000030
C101 067T 3051013CT EC 100uF 16V KM 6.3x11mm 9JR6700000018
