124
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-32G4U/G4D
LC-37G4U/G4D
CABINET AND MECHANICAL PARTS
LC-32G4U/G4D
1 CCABAA513WJ02 J Front Cabinet Ass’y BG
1-1
Not Available
– Front Cabinet —
1-2 GCOVAA677WJSA J R/C LED Cover AF
1-3 HBDGBA037WJSA J Badge “SHARP” AM
1-4 PSPAGA188WJZZ J Spacer AA
1-5 PSPAHA298WJZZ J Himeron Mask A, x2 AC
1-6 PSPAHA299WJZZ J Himeron Mask B, x2 AC
1-7 TLABZA635WJZZ J Energy Label AC
1-8 TLABZA676WJZZ J Pop Label AC
2 CCABBA358WJ02 J
Rear Cabinet Ass’y, (LC-32G4U)
BK
2 CCABBA444WJ01 J
Rear Cabinet Ass’y, (LC-32G4D)
2-1
Not Available
– Rear Cabinet —
2-2 GCOVAA454WJKE J Hole Cover, x4 AC
2-3 GCOVAA758WJKA J Hole Cover L AG
2-4 GCOVAA759WJKA J Hole Cover R AG
2-5 GCOVAA784WJKB J Stand WR Cover AE
2-6 HiNDP5733CESF J AQUOS Label AD
2-7 HiNDPA754WJSB J SP Terminal Indicator AD
2-8 HiNDPA786WJSB J System Cable Indicator AE
2-9 HiNDPA828WJSA J Model Indicator
(LC-32G4U)
AH
2-9 HiNDPB111WJSA J Model Indicator
(LC-32G4D)
2-10 HiNDPA834WJSB J Hole Cover Indicator AD
2-11 LHLDWA043WJKZ J Wire Holder AB
2-12 LHLDWA044WJKZ J Wire Holder AB
2-13 LHLDWA048WJKZ J Wire Holder AB
2-14 LHLDZA349WJZZ J SP Fixing Holder, x2 AG
2-15 PSPAGA172WJZZ J Spacer, x4 AA
2-16 XEBS930P08000 J Screw, x2 AA
2-17 XEBSN30P10000 J Screw, x8 AA
3 CCOVAA735WJ02 J Top Control Cover Ass’y AT
3-1
Not Available
– Top Control Cover —
3-2 JBTN-A253WJKB J Control Button AH
3-3 JBTN-A254WJKB J Power Button AG
3-4 MSPRCA015WJFW J Power Button Spring AB
3-5 XEBSN30P08000 J Screw, x2 AA
4 CDAi-A105WJ06 J Stand BY
4-1 GDAi-A105WJKB J Stand Base BB
4-2 GDAi-A116WJSB J Stand Support AY
4-3 GDAi-A117WJF8 J Swivel Base AP
4-4 LANGKA218WJSA J Base Angle BF
4-5 LX-NZA013WJFN J Nut AE
4-6 MHNG-A073WJSB J Hinge BK
4-7 PSPAZA476WJZZ J Spacer, x4 AC
4-8 PSPAZA477WJZZ J Spacer, x4 AD
4-9 XCSS940P25000 J Screw, x10 AB
4-10 XEBS940P10000 J Screw, x12 AB
5
Not Available
–
32 Wide LCD Panel Unit Ass’y
—
5-1 RLCDTA028WJZZ J 32 Wide LCD Panel Unit ER
5-2 CANGKA221WJ01 J Fixing Metal Ass’y AM
5-2-1
Not Available
– Fixing Metal —
5-2-2 PSPAKA049WJKZ J Spacer AC
5-3 CANGKA222WJ01 J Fixing Metal Ass’y AP
5-3-1
Not Available
– Fixing Metal —
5-3-2 PSPAKA042WJKZ J Spacer AC
5-3-3 PSPAKA048WJKZ J Spacer AC
5-4 CANGKA241WJ01 J Fixing Metal Ass’y AK
5-4-1
Not Available
– Fixing Metal —
5-4-2 PSPAKA041WJKZ J Spacer AC
5-5 CCHSMA097WJ01 J Chassis Unit BZ
5-5-1 LANGKA228WJZZ J Chassis Angle AZ
5-5-2 LANGKA230WJZZ J Stand Angle AL
5-5-3 LANGKA242WJFW J Fixing Metal, x2 AL
5-5-4 LANGKA262WJFW J Fixing Metal AE
5-5-5
Not Available
– Chassis —
5-5-6 LHLDWA029WJKZ J Holder, x2 AC
5-5-7 LHLDWA031WJKZ J Holder, x6 AC
5-5-8 LHLDWA039WJKZ J Holder, x2 AD
5-5-9 LHLDWA041WJKZ J Holder AC
5-5-10 LHLDWA046WJKZ J Holder, x10 AC
5-5-11 LHLDZA316WJKZ J Holder, x8 AD
5-5-12 LHLDZA346WJKZ J Holder, x16 AC
5-5-13 LX-EZA007WJFN J Screw, x2 AB
5-5-14 PCLiC1033CEZZ J Clip AB
5-5-15 PMiR-A040WJZZ J Reflection Mirror BE
5-5-16 PSPAGA187WJ00 J Spacer, x8 AB
5-5-17 PSPAHA329WJZZ J Spacer, x2 AB
5-5-18 PSPAHA330WJZZ J Spacer, x2 AE
5-5-19 PSPAHA338WJZZ J Spacer, x2 AB
5-5-20 PSPAHA339WJZZ J Spacer AD
5-5-21 PSPAKA043WJKZ J Spacer, x8 AA
5-5-22 PSPAZA426WJZZ J Spacer AE
5-5-23 PZETKA063WJZZ J Insulator AN
5-5-24 TCAUZA031WJZZ J Caution Card AB
5-5-25 XBBSN40P06000 J Screw AA
5-5-26 XBBS940P08000 J Screw, x2 AB
5-5-27 PSPAHA373WJZZ J Spacer AB
5-6 KLMP-A027WJZZ J Lamp, x8 AZ
5-7 LHLDZA309WJKZ J Lamp Holder, x2 AL
5-8 LHLDZA310WJKZ J Lamp Holder, x2 AM
5-9 LX-BZA051WJFN J Screw, x5 AB
5-10 PCOVUA027WJZZ J Diffusion Panel BG
5-11 PSHEPA167WJZZ J Reflection/Deflection Sheet BX
5-12 PSHEPA168WJZZ J Prism Sheet BN
5-13 PSHEPA169WJZZ J Diffusion Sheet AW
5-14 LX-BZA052WJFN J Screw, x8 AA
5-15 XBBSN30P08000 J Screw, x6 AA
5-16 XEBSN30P10000 J Screw, x6 AA
5-17 PSPAZA490WJZZ J Spacer AC
5-18 PSPAZA491WJZZ J Spacer AF
6 CHLDZA330WJ02 J Bracket L Ass’y AW
6-1 GLEGGA025WJZZ J Foot, x2 AB
6-2 LANGKA258WJSA J Fixing Metal AQ
6-3
Not Available
– Bracket Cover —
6-4 LHLDZA357WJKA J Reuse Holder AD
6-5 PSPAZA384WJZZ J Spacer AD
6-6 XEBS930P08000 J Screw, x2 AA
7 CHLDZA335WJ02 J Bracket R Ass’y AW
7-1 GLEGGA025WJZZ J Foot, x2 AB
7-2 LANGKA258WJSA J Fixing Metal AQ
7-3
Not Available
– Bracket Cover —
7-4 LHLDZA357WJKA J Reuse Holder AD
7-5 PSPAZA384WJZZ J Spacer AD
7-6 XEBS930P08000 J Screw, x2 AA
8
Not Available
– Speaker Panel Ass’y —
8-1 CPNLSA020WJ02 J Panel Ass’y BR
8-2 RSP-ZA054WJN1 J Speaker (L) BU
9
Not Available
– Speaker Panel Ass’y —
9-1 CPNLSA020WJ04 J Panel Ass’y BR
9-2 RSP-ZA054WJN2 J Speaker (R) BU
10 XBBS940P06000 J Screw, x2 AA
11 DUNTKC268VJ04 J LCD CONT Unit CK
12 DKEYHC269VJ12 J TMDS RX Unit BU
13 DUNTKC274UJ02 – KEY Unit —
14 DUNTKC275UJ02 – R/C LED Unit —
15 DUNTKC276UJ02 – SP TERMINAL Unit —
16 RDENCA058WJZZ – POWER SUPPLY Unit —
(LC-32G4U)
16 RDENCA059WJZZ – POWER SUPPLY Unit —
(LC-32G4D)
17 RUNTKA069WJZZ – INVERTER-1 Unit —
18 RUNTKA070WJZZ – INVERTER-2 Unit —
19 RUNTKA071WJZZ – INVERTER-1 GND Unit —
20 RUNTKA072WJZZ – INVERTER-2 GND Unit —
21 QPWBMC494WJPZ J FPC AM
22 LHLDW1046CEZZ J Wire Holoder AA
23 QCNW-C102WJN1 J Connecting Cord AK
24 QCNW-C102WJN2 J Connecting Cord AL
25 QCNW-C051WJQZ J Connecting Cord AC
To Next Page
