32″&42″&50″LCD TV Best Buy LC-32LB261U- LC-42LB261U- LC-50LB261U
77
Note: The following information of initial version BOM are only for reference of repair, not place
the order as the basis and are subject to change without notice. Please base on RSPL or Service
BOM (http://cs.tpv.com.cn), thank you!
12. BOM List
Assembly Parts list for Model LC-32LB261U
Location Part No. Description Remark
0M1G1030 6 47 CR3 SCREW
036T 600 18118 NONWOVEN FABRTC
0M1G 130 6 47 CR3 SCREW 3X6
0M1G1030 6 47 CR3 SCREW
0M1G1030 6 47 CR3 SCREW
0M1G1030 8 47 CR3 SCREW
0M1G1730 6120 SCREW 3X6
0M1G1730 6120 SCREW 3X6
0M1G1730 6120 SCREW 3X6
0M1G1730 8120 SCREW
0M1G1740 14 47 CR3 SCREW
0Q1G 140 6120 SCREW
0Q1G 940 8 47 CR3 SCREW 4X8
0Q1G 130 5120 SCREW
SP01 378G0110567YDQ 8 OHM 11W 132X34 0 UNIT
ECN409 395G179E51HC05 FFC CABLE 51P 382MM 0.5MM
ECN601 395G801404RD33 HARNESS 4P PITCH2.0-B&R+B&W 800+550MM
ECN401 395G801410LC49 HARNESS 10P PITCH2.0-5P PITCH1.25+4P PI
ECN701 395G801416RC77 HARNESS 16P PITCH2.0-12P PITCH2.0 180MM
708GJB4101SX01 BBY 40HQ (1160 NA)
X44G9005136050 CORNER PAPER
052G 1185 1 BIG TAPE(Y1200141)
SMTF-U403 100TYMVK007KTX MCU ASSY-056G2233 34
E750 LCA315HVN05AC92Q0X PANEL TPT315B5-HVN05 S520D
P33T0637ADTZ1T0200 COVER_KEY
P33T0638ADT01L0100 KEY TV396W-14D-D4-13FOJ
P33T070900101C0100 LENS
P34T21100GM0HG0100 REAR_COVER TV315W-14C-C12-D2H
P34T2249ADT01L0100 BASE TV32WSL10VIZ3VIZ3VIZ3
P34T2250ADTZ1T01BA DECO_LOGO TV32W-12H-EA-HA1
Q02G707105000100XL BOLT
Q02G708105000100HX BOLT
Q11G701015000L00JY PCB-SUPPORT
Q36T 600 28 11 GP FIBER PLATE
Q36T 600 30 8 NONWOVEN FABRIC
Q36T 600 35 18 BGP NON-WOVEN FABRIC
Q44T3121510522 SPONGE
Q44T3121510537 PU FOAM
Q44T3231 21 18 CUSHION
Q45G99010TV05100X1 PROTECT BAG
Q52G100205000B00ZA AL FOIL
Q52G130118600000YY TAPE
Q52G15010TV0070WXW TAPE_INSULATING
Q52G1501150523AWBK TAPE_INSULATING
Q52G160119100A00YY TAPE
X11G703001200000JY WIRE-CLIP
X12G8009 1 RUBBER FOOT
