LC-42LB261U Sharp 42" LED TV
www.sharpusa.com
VGA (most common)
1 Make sure that your TV’s power cord is unplugged and the computer is turned off.
2 Connect a VGA cable (not provided) to the PC IN jack on the back of your TV and to the VGA jack on the computer.
3 Connect an audio cable (not provided) to the PC/DVI AUDIO IN jack on the back of your TV and to the AUDIO OUT
(headphone) jack on the computer.
4 Plug your TV’s power cord into a power outlet, then turn on your TV and the computer.
5 Press INPUT to open the INPUT SOURCE list.
6 Press
S or T to select PC, then press ENTER.
7 Adjust the display properties on the computer, if necessary.
Audio cable
VGA cable
Back of TV
VGA cable
connector
Audio cable
connector
PC IN jack PC/DVI
AUDIO IN
jack
On your TV
