LC-60E77UN/LC-65E77UM/LC-C6077UN/LC-C6577UM
2 – 1
LC60E77UN
Service Manual
CHAPTER 2. OPERATION MANUAL
[1] Parts Name
TV (Front)
OPC indicator
OPC sensor
*
POWER indicator
Remote control sensor
TV (Rear/Side)
POWER
button
MENU
button
INPUT
button
Channel
buttons
(CH /)
Volume
buttons
(VOL /)
RS-232C terminal
DIGITAL AUDIO
OUTPUT terminal
INPUT 7 terminal
(HDMI)
INPUT 8 terminal
(HDMI)
INPUT 6 terminal (HDMI)
INPUT 4 terminal (PC-IN)
AUDIO terminal (shared for INPUT 4 and INPUT 6)*4
Antenna/Cable in
INPUT 1 terminals
INPUT 2 terminals
AUDIO OUTPUT
terminals
LC-60E77UN/
LC-C6077UN
LC-65E77UM/
LC-C6577UM
AC INPUT
terminal
INPUT 3
terminals
SERVICE
terminal
INPUT 5
terminal
(HDMI)
*1
*2
*3
*1
*1 External equipment connection.
*2 Button operations.
*3 Connecting the AC cord.
*4 Details on the PC Audio Select function.
• The illustrations in this operation manual are for explanation purposes and may vary slightly from the actual operations.
• The examples used throughout this manual are based on the LC-65E77UM model.
* OPC: Optical Picture Control
