38
R-1405
R-1406
PARTS LIST
Note: The parts marked “
∆∆
∆∆
∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V. "§" MARK: PARTS DELIVERY SECTION
ELECTRIC PARTS
1- 1 FH-DZB016MRY0 M High voltage rectifier assembly 1 AH
1- 2 RC-QZA234WRE0 M High voltage capacitor 1 AP
1- 3 QFS-TA013WRE0 M Temperature fuse 150½C (Magnetron) 1 AE
1- 4 RMOTDA211WRE0 M Turntable motor 1 AL
1- 5 RTHM-A070WRE0 M Thermal cut-out 145½C (Cavity) 1 AF
1- 6 RTHM-0044MRE0 M Thermal cut-out N.O. 60½C (Hood Fan) 1 AH
1- 7 RTRN-B076MRE0 M Power transformer 1 AY
1- 8 RV-MZA288WRE0 M Magnetron 1 BK
1- 9 QFSHDB003MRE0 M Fuse holder 1 AD
1-10 QSW-MA085WRE0 M Primary interlock and door sensing switches 2 AE
1-11 FFS-BA016/KIT M Monitor switch (V-16G-2C25) with fuse (20A) assembly 1 AF
1-12 FACCDB011MRE0 M Power supply cord 1 AQ
1-13 QSOCLB006MRE0 M Oven lamp socket 3 AE
1-14 FMOTEA469WRKZ M Hood fan motor 1 BA
1-15 RMOTEB031MRE0 M Fan motor 1 AT
1-16 RLMPTA068WRE0 M Oven lamp 3 AE
CABINET PARTS
2- 1 LSTY-B026MRP0 M Rear stay 1 AE
2- 2 PDIF-B030MRF0 M Hood exhaust louver [R-1405] 1 AQ
2- 2 PDIF-B031MRF0 M Hood exhaust louver [R-1406] 1 AQ
2- 3 GDAI-B065MRP0A M Base plate R 1 AG
2- 4 HDECQB027MRF0 M Front panel L [R-1405] 1 AL
2- 4 HDECQB028MRF0 M Front panel L [R-1406] 1 AL
2- 5 GCABUB103MRP0 M Outer case cabinet [R-1405] 1 AZ
2- 5 GCABUB105MRP0 M Outer case cabinet [R-1406] 1 AZ
2- 6 TMAPCB074MRR0 M Schematic diagram 1 AB
2- 7 FANGKB009MRY0 M Hood lamp glass assembly [R-1405] 1 AN
2- 7 FANGKB010MRY0 M Hood lamp glass assembly [R-1406] 1 AM
2-7-1 LANGQB016MRP0 M Hood lamp glass angle [R-1405] 1 AG
2-7-1 LANGQB020MRP0 M Hood lamp glass angle [R-1406] 1 AG
2-7-2 PGLSPB004MRE0 M Hood lamp glass 1 AH
2- 8 PCOVPB096MRT0 M Base cover [R-1405] 1 AV
2- 8 PCOVPB097MRT0 M Base cover [R-1406] 1 AV
CONTROL PANEL PARTS
3- 1 CPWBFB069MRU0 M Control unit 1 BE
3- 1A QCNCMA017JDZZ M 3-pin connector CN-A 1 AA
3- 1B QCNCMA431DRE0 J 2-pin connector CN-B 1 AA
3- 1C QCNCMA275DRE0 J 2-pin connector CN-E 1 AB
3- 1D FW-VZB189MRE0 M Lead wire harness CN-C 1 AB
C1 RC-KZA087DRE0 J Capacitor 0.1 uF 50V 1 AB
C2 VCEAB31VW108M J Capacitor 1000 uF 35V 1 AF
C21 VCEAB31VW106M J Capacitor 10 uF 35V 1 AB
C100 RC-QZB014MRE0 M Capacitor 7 uF 230V 1 AK
D1-4 RH-DZA006PRE0 J Diode (1N4002) 4 AD
D20-22 VHD1SS270A/-1 J Diode (1SS270A) 3 AA
D24-25 VHD1SS270A/-1 J Diode (1SS270A) 2 AA
D40 VHD1SS270A/-1 J Diode (1SS270A) 1 AA
Q21 VSKRC243M//-3 J Transistor (KRC243M) 1 AB
R1 VRS-L63DA391J J Resistor 390 ohm 2W 1 AB
R2 VRS-B13AA751J J Resistor 750 ohm 1W 1 AB
R30 VRD-B12EF332J J Resistor 3.3k ohm 1/4W 1 AA
RY1-2 RRLY-A113DRE0 M Relay (DU24D1-1PR(M)) 2 AG
RY4-5 RRLY-B004MRE0 M Relay (FTR-F3AA024E) 2 AG
SP1 RALM-A014DRE0 J Buzzer (PKM22EPT) 1 AG
T1 RTRNPB018MRE0 M Transformer 1 AS
VRS1 RH-VZB002MRE0+ M Varistor (JVR-10S471J) 1 AE
3- 1-1 LHLD-B018MRF0 M LCD holder 1 AC
3- 1-2 PSHEPB023MRE0 M LED sheet 1 AR
3- 2 FPNLCB424MRK0 M Control panel sub. assembly [R-1405] 1 AX
3- 2 FPNLCB425MRK0 M Control panel sub, assembly [R-1406] 1 AX
3- 2-1 FUNTKB368MRE0 M Key unit [R-1405] 1 AQ
3- 2-1 FUNTKB367MRE0 M Key unit [R-1406] 1 AQ
3- 2-2 JBTN-B140MRF0 M Open button [R-1405] 1 AE
REF. NO. PART NO. § DESCRIPTION Q'TY CODE
