R-220DW
R-230DK
R-230DW
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
*
*
*
*
∆
*
ELECTRIC PARTS
1- 1 QSW-MA137WRE0 Secondary interlock switch & door sensing switch 2 AH
1- 2 FFS-BA025WRKZ C/T fuse & monitor switch(AM51620C53Y1) assembly 1 AS
1- 3 FACCDA086WREZ Power supply cord 1 AN
1- 3 FACCDA081WRE0 Power supply cord (Interchangeable) 1 AP
1- 4 QSOCLA021WRE0 Oven lamp socket 1 AH
1- 5 FH-DZA081WRK0 High voltage rectifier 1 AQ
1- 6 RC-QZA228WRE0 High voltage capacitor 1 AT
1- 6 RC-QZA200WRE0 High voltage capacitor (Interchangeable) 1 AV
1- 7 RMOTEA355WRE0 Fan motor 1 AU
1- 7 RMOTEA383WRE0 Fan motor (Interchangeable) 1 AV
1- 8 RV-MZA226WRE0 Magnetron 1 BE
1- 9 RLMPTA030WRE0 Oven lamp 1 AF
1- 9 RLMPTA068WRE0 Oven lamp (Interchangeable) 1 AG
1-10 RMOTDA211WRE0 Turntable motor 1 AS
1-10 RMOTDA186WRE0 Turntable motor (Interchangeable) 1 AW
1-11 RTHM-A078WRE0 Thermal cut-out 125˚C 1 AK
1-12 RTRN-A604WRZZ Power transformer 1 BH
CABINET PARTS
2- 1 GCABUA696WRP0 Outer case cabinet [R-220DW] 1 AY
2- 1 GCABUA756WRPZ Outer case cabinet [R-230DK] 1 AY
2- 1 GCABUA696WRP0 Outer case cabinet [R-230DW] 1 AY
2- 2 GDAI-A304WRW0 Bottom plate 1 AF
2- 3 GLEGPA074WRE0 Foot 2 AC
CONTROL PANEL PARTS
3- 1 DPWBFC027WRUZ Control unit [R-220DW] 1 BA
3- 1 DPWBFC028WRUZ Control unit [R-230DK] 1 BA
3- 1 DPWBFC028WRUZ Control unit [R-230DW] 1 BA
3- 2 FPNLCB477WRKZ Control panel frame with key unit and LCD [R-220DW] 1 BB
3- 2 FPNLCB481WRKZ Control panel frame with key unit and LCD [R-230DW] 1 BB
3- 2 FPNLCB482WRKZ Control panel frame with key unit and LCD [R-230DK] 1 BB
3- 2-1 FUNTKA972WREZ Key unit [R-220DW] 1 AT
3- 2-1 FUNTKA976WREZ Key unit [R-230DW] 1 AT
3- 2-1 FUNTKA977WREZ Key unit [R-230DK] 1 AT
3- 2-2 RLCDSA045DRE0 Liquid crystal display 1 AM
3- 3 QCNC-A012WRE0 Rubber connector 1 AF
3- 4 XEPSD30P08XS0 Screw; 3mm x 8mm 3 AA
OVEN PARTS
4- 1 PHOK-A105WRF0 Latch hook 1 AL
4- 2 LANGQA477WRW0 Light mount plate 1 AY
4- 3 PCUSUA502WRP0 Waterproof cushion 2 AD
4- 4 LBNDKA038WRP0 Capacitor holder 1 AF
4- 5 NFANJA029WRE0 Fan blade 1 AL
4- 6 PDUC-A694WRF0 Fan duct 1 AG
4- 7 ************* Oven cavity (Not replaceable part) 1--
4- 8 GLEGPA073WRF0 Leg 1 AD
4- 9 LANGTA318WRP0 Chassis support 1 AE
4-10 PCUSGA389WRP0 Cushion 1 AG
4-11 PCOVPA276WRE0 Waveguide cover 1 AM
4-12 PCOVPA342WRF0 B-cover Right 1 AH
4-13 PCOVPA343WRF0 B-cover Left 1 AH
4-14 PCUSUA443WRP0 Cushion 2 AE
4-15 PDUC-A700WRF0 Air separator 1 AN
4-16 PPACGA097WRE0 O-ring 1 AG
4-17 PCUSUA474WRP0 Cushion 1 AC
DOOR PARTS
5- 1 FDORFA321WRT0 Door panel 1 AT
5- 2 GWAKPA628WRF0 Door frame [R-220DW] 1 AY
5- 2 GWAKPA709WRFZ Door frame [R-230DK] 1 AY
5- 2 GWAKPA628WRF0 Door frame [R-230DW] 1 AY
5- 3 HPNL-A738WRRZ Door screen 1 AS
5- 4 LSTPPA175WRF0 Latch head 1 AE
5- 5 MSPRTA084WRE0 Latch spring 1 AB
5- 6 PSHEPA622WRE0 Sealer film 1 AG
∆
∆
∆
∆
