R-22GT-F
R-22GV-F
42
∆
∆
∆
∆
REF. NO. PART NO. DESCRIPTION Q'TY CODE
IC3 RIC--A025BDE0 IC (KID65004AP) 1 AE
LED1 VHPSL3966T/1B Light emitting diode 1 AS
Q1 RIC--A022BDE0 IC (KI2A7805PI) 1 AE
Q2 VSDTA123ES/-3 Transistor (DTA123ES) 1 AA
Q3 RH-TZA036CBE0 Transistor (KRC101M) 1 AA
Q20 VSDTB143ES/-3 Transistor (DTB143ES) 1 AC
Q21 RH-TZA036CBE0 Transistor (KRC101M) 1 AA
Q22-23 VSDTD143ES/-3 Transistor (DTD143ES) 2 AC
Q60 RH-TZA037CBE0 Transistor (KRA101M) 1 AA
R3-5 VRD-Q12EF472J Resistor 4.7k ohm 1/4W 3 AA
R30 VRD-Q12EF101J Resistor 100 ohm 1/4W 1 AA
R31 VRD-Q12EF153J Resistor 15k ohm 1/4W 1 AA
R32 VRD-Q12EF272J Resistor 2.7k ohm 1/4W 1 AA
R33 VRD-Q12EF472J Resistor 4.7k ohm 1/4W 1 AA
R40 VRD-Q12EF272J Resistor 2.7k ohm 1/4W 1 AA
R50-58 VRD-Q12EF101J Resistor 100 ohm 1/4W 9 AA
R60 VRD-Q12EF112J Resistor 1.1k ohm 1/4W 1 AA
R61 VRD-Q12EF472J Resistor 4.7k ohm 1/4W 1 AA
R62 VRD-Q12EF333J Resistor 33k ohm 1/4W 1 AG
R63 VRD-Q12EF272J Resistor 2.7k ohm 1/4W 1 AA
R64 VRD-Q12EF472J Resistor 4.7k ohm 1/4W 1 AA
R65 VRD-Q12EF682J Resistor 6.8k ohm 1/4W 1 AA
R66 VRD-Q12EF472J Resistor 4.7k ohm 1/4W 1 AA
R70-71 VRD-Q12EF472J Resistor 4.7k ohm 1/4W 2 AA
R80-88 VRD-Q12EF472J Resistor 4.7k ohm 1/4W 9 AA
R100 VRN-R12EK821F Resistor 820 ohm (F) 1/4W 1 AA
R101 VRD-Q12EF333J Resistor 33k ohm 1/4W 1 AG
R102 VRD-Q12EF472J Resistor 4.7k ohm 1/4W 1 AA
RY1 RRLY-A071DRE0 Relay (OJE-SS-112LM) 1 AG
RY2-3 RRLY-A094DRE0 Relay (OMIF-S-112LM) 2 AN
SP1 RALM-A014DRE0 Buzzer (PKM22EPT) 1 AG
T1 RTRNPA094DRE0 Touch control transformer 1 AQ
CT1 RTRN-026CHRE0 Current transformer 1 AH
VRS1 RH-VZA034DRE0 Varistor (10G471K) 1 AD
ZD2 VHEHZ4A2///-1 Zener diode (HZ4A2) 1 AA
3- 2 FPNLCB148WRK0 Control panel frame with key unit [R-22GV-F] 1 AZ
3- 2 FPNLCB468WRK0 Control panel frame with key unit [R-22GT-F] 1 AZ
3- 2-1 FUNTKA774WRE0 Key unit [R-22GV-F] 1 AT
3- 2-1 FUNTKA773WRE0 Key unit [R-22GT-F] 1 AT
3- 2-2 HDECAA195WRP0 Decoration metal fittings 1 AP
3- 2-3 PCUSUA417WRP0 Cushion 1 AB
3- 3 LANGTA243WRW0 Control panel mounting angle 1 AF
3- 4 XEPS730P10XS0 Screw; control unit mounting 5 AA
3- 5 XEPS740P12000 Screw; control panel mounting angle mounting 2 AA
3- 6 LX-BZA138WREZ Screw; decoration panel mounting for earth 1 AB
OVEN PARTS
4- 1 PGLSPA632WREZ Lamp glass 1 AG
4- 2 FDUC-A345WRY0 Exhaust duct assembly 1 AP
4- 3 ************* Oven cavity (Not a replaceable part) 1 --
4- 4 PFILWA063WRPZ Oven light screen (Inside) 1 AD
4- 5 MLEVPA153WRF0 Switch lever A 1 AC
4- 6 MLEVPA154WRF0 Switch lever B 1 AC
4- 7 MLEVPA155WRF0 Switch lever C 1 AC
4- 8 MSPRCA075WRE0 Switch spring A 1 AB
4- 9 MSPRCA076WRE0 Switch spring B 2 AB
4-10 PHOK-A081WRF0 Latch hook 1 AP
4-11 MHNG-A216WRM0 Lower oven hinge 1 AG
4-12 MSPRCA101WRE0 Switch lever spring C 1 AC
4-13 PCUSU0407WRP0 Cushion 2 AA
4-14 FGLSPA067WRYZ Ceramic shelf 1 BH
4-15 FPLT-A013WRYZ Stirrer antenna upper assembly 1 AX
4-16 FPLT-A009WRY0 Stirrer antenna lower assembly 1 AV
4-17 LANGKA762WRP0 Partition angle R 1 AE
4-18 LANGQA228WRW0 Oven lamp mounting plate 1 AF
4-19 LBNDKA075WRP0 Capacitor holder 1 AD
4-20 PGIDHA054WRW0 Water-proof cover 1 AF
4-21 NSFTPA031WRF0 Antenna motor shaft 2 AH
4-22 LANGQA622WRPZ Noise filter angle 1 AK
4-23 PCUSUA417WRP0 Cushion 1 AB
4-24 MHNG-A215WRM0 Upper oven hinge 1 AG
4-25 PCUSUA413WRP0 Cushion 1 AG
4-26 PCUSUA415WRP0 Cushion 1 AC
4-27 PDUC-A729WRF0 Air duct 1 AL
