R-310AK
R-330AK
R-330AW
REF. NO. PART NO. DESCRIPTION Q'TY CODE
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
ZD1 VHEHZ4C3///-1 Zener diode (HZ4C-3) 1 AA
3- 2 FPNLCB264WRK0 Control panel frame with key unit 1 BB
3- 2- 1 FUNTKA786WRE0 Key unit 1 AX
3- 3 PSHEPA585WRE0 LED sheet 1 AM
3- 4 LHLD-A164WRF0 LED holder 1 AD
3- 5 QCNC-A007WRE0 Rubber connector 1 AE
3- 6 RLCDSA038DRE0 Liquid crystal display 1 AN
3- 7 JBTN-B028WRF0 Open button 1 AG
3- 8 MSPRCA050WRE0 Open button spring 1 AB
3- 9 XEPSD30P08XS0 Screw: 3mm x 8mm 4 AA
OVEN PARTS
4- 1 MLEVFA082WRE0 Actuator 1 AD
4- 2 PHOK-A098WRF0 Switch holder 1 AP
4- 3 PHOK-A095WRF0 Latch hook 1 AN
4- 4 LBNDKA099WRW0 Capacitor holder 1 AD
4- 5 NFANJA029WRE0 Fan blade 1 AL
4- 6 PDUC-A652WRP0 Fan duct 1 AU
4- 7 FOVN-A371WRT0 Oven cavity 1 BC
4- 8 LANGFA180WRW0 Chassis support 1 AM
4- 9 LANGQA452WRP0 Partition angle 1 AK
4-10 LANGQA454WRP0 MG thermo angle 1 AH
4-11 MLEVPA194WRF0 Switch lever 1 AG
4-12 NCPL-A045WRF0 Coupling 1 AH
4-13 PCUSGA385WRP0 Cushion 1 AK
4-14 PCOVPA275WRE0 Waveguide cover 1 AR
4-15 PCUSGA339WRP0 Cushion 1 AG
4-16 PCUSUA212WRP0 Cushion 1 AB
4-17 PCUSUA235WRP0 Cushion 1 AF
4-18 PCUSUA376WRP0 Cushion 1 AG
4-19 PCUSUA278WRP0 Cushion 1 AC
4-20 PGIDHA058WRP0 MG. air guide 1 AF
4-21 PPACGA041WRE0 Cushion 1 AE
4-22 PPACGA084WRF0 TTM packing 1 AF
DOOR PARTS
5- 1 FDORFA303WRT0 Door panel 1 BA
5- 2 PSHEPA382WRE0 Sealer film 1 AH
5- 3 GWAKPA448WRR0 Door frame 1 AW
5- 4 HPNL-A662WRE0 Door screen 1 AK
5- 5 GCOVHA370WRF0 Choke cover 1 AM
5- 6 LSTPPA139WRF0 Latch head 1 AF
5- 7 MSPRTA084WRE0 Latch spring 1 AB
5- 8 LSTPPA162WRF0 Door stopper 1 AE
5- 9 XCPSD40P06000 Screw : 4mm x 6mm 2 AA
MISCELLANEOUS
6- 1 FROLPA079WRK0 Turntable support 1 AQ
6- 2 NTNT-A079WRE0 Turntable tray 1 AR
6- 3 FW-VZB547WRE0 Main wire harness (until September 1996 production) 1 AX
6- 3 FW-VZB572WRE0 Main wire harness (from October 1996 production) 1 BC
6- 4 QW-QZA150WRE0 High voltage wire B 1 AF
6- 5 PZET-A012WRE0 Terminal insulator 1 AB
6- 6 TCAUAA166WRR0 DHHS caution label 1 AC
6- 7 TCAUAA200WRR0 Monitor caution label 1 AB
6- 8 TCADCA611WRR0 Instruction book 1 AE
6- 9 TSPCNC381WRR0 Rating label 1 AF
SCREWS,NUTS AND WASHERS
7- 1 XFPSD40P08K00 Screw : 4mm x 8mm 7 AA
7- 2 XFPSD30P06000 Screw : 3mm x 6mm 1 AA
7- 3 XHTSD40P08RV0 Screw : 4mm x 8mm 4 AA
7- 4 XHTSD40P12RV0 Screw : 4mm x 12mm 1 AA
7- 5 XOTSD40P12RV0 Screw : 4mm x 12mm 8 AA
7- 6 XOTSD40P12000 Screw : 4mm x 12mm 12 AA
7- 7 XOTSF40P08000 Screw : 4mm x 8mm 1 AA
