Sharp R-310AK User Manual

41
R-310AK
R-330AK
R-330AW
REF. NO. PART NO. DESCRIPTION Q'TY CODE
R72-75 VRD-B12EF104J Resistor 100k ohm 1/4W 4 AA
R80 VRD-B12EF105J Resistor 1M ohm 1/4W 1 AA
R90 VRS-B13AA331J Resistor 330 ohm 1W 1 AA
RY1 RRLY-A075DRE0 Relay (OJE-SS-124LM) 1 AG
RY2 RRLY-A076DRE0 Relay (OMIF-S-124LM) 1 AK
SP40 RALM-A014DRE0 Buzzer (PKM22EPT-THAI) 1 AG
T1 RTRNPA020DRE0 Transformer 1 AM
VRS1 RH-VZA034DRE0 Varistor (10G471K) 1 AD
ZD1 VHEHZ161///-1 Zener diode (HZ16-1) 1 AA
ZD2 VHEHZ5C2///-1 Zener diode (HZ5C2) 1 AA
ZD3 VHEHZ4A2///-1 Zener diode (HZ4A2) 1 AA
3- 2 FPNLCB262WRK0 Control panel frame with key unit [R-330AK] 1 BB
3- 2 FPNLCB263WRK0 Control panel frame with key unit [R-330AW] 1 BB
3- 2- 1 FUNTKA784WRE0 Key unit [R-330AW] 1 AY
3- 2- 1 FUNTKA785WRE0 Key unit [R-330AK] 1 AX
3- 3 PSHEPA585WRE0 LED sheet 1 AM
3- 4 LHLD-A164WRF0 LED holder 1 AD
3- 5 QCNC-A007WRE0 Rubber connector 1 AE
3- 6 RLCDSA039DRE0 Liquid crystal display 1 AN
3- 7 JBTN-B028WRF0 Open button [R-330AK] 1 AG
3- 7 JBTN-B029WRF0 Open button [R-330AW] 1 AG
3- 8 MSPRCA050WRE0 Open button spring 1 AB
3- 9 XEPSD30P08XS0 Screw: 3mm x 8mm 4 AA
OVEN PARTS
4- 1 MLEVFA082WRE0 Actuater 1 AD
4- 2 PHOK-A098WRF0 Switch holder 1 AP
4- 3 PHOK-A095WRF0 Latch hook 1 AN
4- 4 LBNDKA099WRW0 Capacitor holder 1 AD
4- 5 NFANJA029WRE0 Fan blade 1 AL
4- 6 PDUC-A652WRP0 Fan duct 1 AU
4- 7 FOVN-A371WRT0 Oven cavity 1 BC
4- 8 LANGFA180WRW0 Chassis support 1 AM
4- 9 LANGQA452WRP0 Partition angle 1 AK
4-10 LANGQA454WRP0 MG thermo angle 1 AH
4-11 MLEVPA194WRF0 Switch lever 1 AG
4-12 NCPL-A045WRF0 Coupling 1 AH
4-13 PCUSGA385WRP0 Cushion 1 AK
4-14 PCOVPA275WRE0 Waveguide cover 1 AR
4-15 PCUSGA339WRP0 Cushion 1 AG
4-16 PCUSUA212WRP0 Cushion 1 AB
4-17 PCUSUA235WRP0 Cushion 1 AF
4-18 PCUSUA376WRP0 Cushion 1 AG
4-19 PCUSUA278WRP0 Cushion 1 AC
4-20 PGIDHA058WRP0 MG. air guide 1 AF
4-21 PPACGA041WRE0 Cushion 1 AE
4-22 PPACGA084WRF0 TTM packing 1 AF
4-23 PCOVPA254WRP0 Air duct 1 AP
DOOR PARTS
5- 1 FDORFA303WRT0 Door panel 1 BA
5- 2 PSHEPA382WRE0 Sealer film 1 AH
5- 3 GWAKPA446WRR0 Door frame [R-330AK] 1 AW
5- 3 GWAKPA450WRR0 Door frame [R-330AW] 1 AW
5- 4 HPNL-A662WRE0 Door screen [R-330AK] 1 AK
5- 4 HPNL-A663WRR0 Door screen [R-330AW] 1 AL
5- 5 GCOVHA370WRF0 Choke cover 1 AM
5- 6 LSTPPA139WRF0 Latch head 1 AF
5- 7 MSPRTA084WRE0 Latch spring 1 AB
5- 8 LSTPPA162WRF0 Door stopper 1 AE
5- 9 XCPSD40P06000 Screw : 4mm x 6mm 2 AA
MISCELLANEOUS
6- 1 FROLPA079WRK0 Turntable support 1 AQ
6- 2 NTNT-A079WRE0 Turntable tray 1 AR
6- 3 FW-VZB547WRE0 Main wire harness (until September 1996 production) 1 AX
6- 3 FW-VZB572WRE0 Main wire harness (from October 1996 production) 1 BC
6- 4 QW-QZA150WRE0 High voltage wire B 1 AF
6- 5 PZET-A012WRE0 Terminal insulator 1 AB
6- 6 TCAUAA166WRR0 DHHS caution label 1 AC
6- 7 TCAUAA200WRR0 Monitor caution label 1 AB
6- 8 TCADCA610WRR0 Instruction book 1 AF
6- 9 TSPCNC379WRR0 Rating label [R-330AK] 1 AF
