37
R-330DK
R-330DW
*
*
∆
*
*
∆
PARTS LIST
Note: The parts marked “∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
ELECTRIC PARTS
1- 1 QSW-MA147WRZZ 2nd interlock switch / door sensing switch 2 AG
1- 2 QFSHDA009WRE0 Fuse holder 1 AH
1- 3 FFS-BA021WRK0
Monitor fuse 20A and monitor switch (V-16G-2C25) assembly 1AL
1- 4 RTHM-A078WRE0 Thermal cut-out 125 deg. 1 AL
1- 5 FACCDA083WRE0 Power supply cord 1 AQ
1- 5 FACCDA085WREZ Power supply cord (Interchangeable) 1 AQ
1- 6 FH-DZA094WRKZ High voltage rectifier assembly 1 AU
1- 7 RC-QZA234WRE0 High voltage capacitor 1 AV
1- 8 RV-MZA288WRE0 Magnetron 1 BK
1- 9 RMOTEA383WRE0 Fan motor 1 AV
1- 9 RMOTEA355WRE0 Fan motor (Interchangeable) 1 AU
1-10 QSOCLA021WRE0 Oven lamp socket 1 AH
1-11 RLMPTA068WRE0 Oven lamp 1 AG
1-11 RLMPTA030WRE0 Oven lamp (Interchangeable) 1 AE
1-12 RMOTDA161WRE0 Turntable motor 1 AS
1-12 RMOTDA211WRE0 Turntable motor (Interchangeable) 1 AS
1-13 RTHM-A080WRE0 Thermal cut-out 145 deg. 1 AP
1-14 RTRN-A603WRZZ Power transformer 1 BM
1-15 FDTCTA197WRK0 AH sensor assebly 1 BC
CABINET PARTS
2- 1 GCABUA744WRPZ Outer case cabinet [R-330DK] 1 BC
2- 1 GCABUA690WRP0 Outer case cabinet [R-330DW] 1 AZ
2- 2 GDAI-A316WRW0 Bottom plate 1 AX
2- 3 GLEGPA074WRE0 Foot 2 AC
2- 4 GLEGPA077WRF0 Leg 1 AH
CONTROL PANEL PARTS
3- 1 DPWBFC044WRKZ Power unit 1 BC
3- 1A QCNCMA446DRE0 2-pin connector (CN-A) 1 AC
3- 1B FW-VZA232DRE0 12pin lead wire (CN-C) 1 AE
3- 1C FW-VZA195DRE0 Switch harness A (SH-A) 1 AD
3- 1D FW-VZA256DREZ Switch harness B (SH-B) 1 AF
C1 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C2 VCEAB31VW108M Capacitor 1000 uF 35V 1 AF
C3 RC-KZA087DRE0 Capacitor 0.1 uF 50V 1 AA
C4-5 VCEAB31VW106M Capacitor 10 uF 35V 2 AA
D1-4 VHD11ES1///-1 Diode (11ES1) 4 AB
D5-8 VHD1SS270A/-1 Diode (1SS270ATA) 4 AA
Q1-2 VS2SB1238//-3 Transistor (2SB1238) 2 AA
Q3 VSKRC243M//-3 Transistor (KRC243M) 1 AB
R1 VRD-B12EF242J Resistor 2.4k ohm 1/4W 1 AA
R2 VRD-B12HF681J Resistor 680 ohm 1/2W 1 AA
R3 VRD-B12HF511J Resistor 510 ohm 1/2W 1 AB
R4 VRD-B12EF270J Resistor 27 ohm 1/4W 1 AB
R5 VRD-B12EF472J Resistor 4.7k ohm 1/4W 1 AA
R6 VRD-B12EF332J Resistor 3.3k ohm 1/4W 1 AA
RY1 RRLY-A076DRE0 Relay (OMIF-S-124LM) 1 AK
RY2 RRLY-A113DRE0 Relay (DU24D1-P(M)-R) 1 AM
SP1 RALM-A014DRE0 Buzzer (PKM22EPT) 1 AG
T1 RTRNPA111DRE0 Transformer 1 AP
VRS1 RH-VZA032DRE0 Varistor (10G471K) 1 AE
ZD1 VHEHZ161///-1 Zener diode (HZ16-1) 1 AA
3- 2 DPWBFC025WRKZ CPU unit 1 BK
3- 3 FPNLCB488WRKZ Control panel frame with key unit [R-330DK] 1 BB
3- 3 FPNLCB489WRKZ Control panel frame with key unit [R-330DW] 1 BB
3- 3-1 FUNTKA983WREZ Key unit [R-330DK] 1 AW
3- 3-1 FUNTKA984WREZ Key unit [R-330DW] 1 AW
3- 4 PSHEPA672WRE0 LED sheet 1 AK
3- 5 LHLD-A185WRF0 LCD holder 1 AL
3- 6 XEPSD30P08XS0 Screw; 3mm x 8mm 4 AA
OVEN PARTS
4- 1 PDUC-A724WRF0 Air separater 1 AU
4- 2 PPACGA084WRF0 TTM packing 1 AF
4- 3 PHOK-A116WRFZ Latch hook 1 AH
4- 4 LBNDKA099WRW0 Capacitor holder 1 AD
