R-3A56
Note: The parts marked "∆" may cause undue microwave exposure.
The parts marked "*" are used in voltage more than 250V.
REF. NO. PART NO. DESCRIPTION Q'TY CODE
∆
∆
∆
*
∆
∆
∆
∆
ZD2 VHEHZ4C3///-1 Zener diode (HZ4C-3) 1 AA
3- 2 FPNLCB104WRK0 Control panel frame with key unit 1 BB
3-2-1 FUNTKA613WRE0 Key unit 1 BA
3- 3 JBTN-A862WRF0 Open button 1 AH
3- 4 MSPRCA050WRE0 Open button spring 1 AB
3- 5 XEPSD30P10XS0 Screw; Control unit mtg. 3 AA
OVEN PARTS
4- 1 PHOK-A085WRF0 Latch hook 1 AQ
4- 2 PCUSGA388WRP0 Cushion 1 AK
4- 3 LBNDKA095WRP0 H.V. capacitor band 1 AM
4- 4 LANGQA343WRP0 Thermal cut-out (Fan) mounting angle 1 AK
4- 5 NFANJA029WRE0 Fan blade 1 AL
4- 6 PDUC-A534WRP0 Fan duct 1 AQ
4- 7 FOVN-A285WRT0 Oven cavity 1 BE
4- 8 FDAI-A171WRY0 Bottom plate R assembly 1 AT
4- 9 GDAI-A235WRP0 Bottom plate L 1 AP
4-10 GLEGPA019WRE0 Foot 4 AD
4-11 LANGFA161WRP0 Chassis support 1 AM
4-12 LANGQA367WRP0 Partition angle 1 AP
4-13 MHNG-A318WRT0 Oven hinge (Upper) 1 AL
4-14 MHNG-A319WRT0 Oven hinge (Lower) 1 AK
4-15 MLEVPA194WRF0 Switch lever 1 AG
4-16 NCPL-A045WRF0 Coupling 1 AH
4-17 PCOVPA274WRP0 Turntable motor cover 1 AH
4-18 PCOVPA275WRE0 Waveguide cover 1 AR
4-19 PCUSGA378WRP0 Cushion 1 AL
4-20 PCUSUA329WRP0 Cushion 1 AC
4-21 PCUSUA376WRP0 Cushion 1 AG
4-22 PDUC-A533WRP0 Air guide 1 AH
4-23 PFILWA041WRE0 Oven lamp filter 1 AF
4-24 PCUSGA339WRP0 Cushion 1 AG
4-25 PPACGA084WRF0 Turntable motor packing 1 AF
4-26 LANGQA368WRP0 Fuse angle (for Australia) 1 AL
4-27 PCLIC0026WRE0 P-clip 1 AA
DOOR PARTS
5 DDORFA670WRK0 Door assembly,complete. 1 BL
5- 1 FDORFA258WRT0 Door panel 1 BD
5- 2 GCOVHA300WRF0 Choke cover 1 AN
5- 3 FWAKPA060WRK0 Door frame assembly 1 AZ
5- 4 LSTPPA120WRF0 Latch head 1 AM
5- 5 MSPRTA081WRE0 Latch spring 1 AA
5- 6 PSHEPA382WRE0 Sealer film 1 AH
5- 7 XEPSD30P06000 Screw: 3mm x 6mm 5 AA
MISCELLANEOUS
6- 1 FROLPA059WRK0 Roller stay 1 AQ
6- 2 NTNT-A046WRF0 Turntable tray 1 AU
6- 3 TGAN-A079WRR0 Warrant card (for New Zealand) 1 AF
6- 4 TINSEA632WRR0 Operation manual 1 AN
6- 5 FW-VZB122WRE0 Switch harness 1 AP
6- 6 FW-VZB230WRE0 Main wire harness (for Australia) 1 AY
6- 6 FW-VZB242WRE0 Main wire harness (for New Zealand) 1 AY
6- 7 QW-QZA187WRE0 High voltage wire A 1 AM
6- 8 LHLDWA034WRE0 Cable clip 1 AG
6- 9 TCAUHA185WRR0 Micro caution (for New Zealand) 1 AD
6-10 TCAUHA055WRR0 K caution label 1 AF
6-11 TSPCNC039WRR0 Name plate (for Australia) 1 AC
6-11 TSPCNC044WRR0 Name plate (for New Zealand) 1 AC
6-12 LHLDWA011WRE0 Purse lock “M” 1 AB
6-13 QTANP0020YBE0 Connector (for Australia) 1 AA
SCREWS, NUTS AND WASHERS
7- 1 XOTSD40P12000 Screw; 4mm x 12mm 17 AA
7- 2 XFPSD40P08K00 Screw; 4mm x 8mm (for Australia) 4 AA
7- 2 XFPSD40P08K00 Screw; 4mm x 8mm (for New Zealand) 6 AA
7- 3 XHTSD40P08RV0 Screw; 4mm x 8mm 2 AA
7- 4 XFPSD30P10000 Screw; 3mm x 10mm 1 AA
7- 5 XOTSD40P12RV0 Screw; 4mm x 12mm 8 AA
7- 6 XVPSD40P20000 Screw; 4mm x 20mm 1 AA
