Siemens 3UG4 User Manual

3UG4501 filling level monitoring relay
5.7 Technical data
3UG4 / 3RR2 monitoring relays
Manual, 05/2016, NEB927043002000/RS-AC/004
97
3UG4501-..A..
3UG4501-..W..
Electromagnetic compatibility
IEC 60947-1 / IEC 61000-6-2 / IEC 61000-6-4
Operating current at 17 V minimum
mA
5
Continuous current
of the DIAZED fuse
link of the output relay
A
4
Resistance against vibration
according to
IEC 60068-2-6
1 ... 6 Hz: 15 mm, 6 ... 500 Hz: 2g
Shock resistance
according to IEC 60068-
2-27
sinusoidal half-wave 15g / 11 ms
Installation altitude
at a height over sea
level maximum
m 2 000
Current carrying capacity
of output relay
• at AC-15
– at 250 V at 50/60 Hz
A
3
– at 400 V at 50/60 Hz
A
3
• at DC-13
– at 24 V
A
1
– at 125 V
A
0.2
– at 250 V
A
0.1
Conductor-bound parasitic coupling BURST
according to IEC 61000-4-4
2 kV
Conductor-bound parasitic coupling
conductor-earth SURGE
according to IEC
61000-4-5
2 kV
Conductor-bound parasitic coupling
conductor-conductor SURGE
according to
IEC 61000-4-5
1 kV
Electrostatic discharge
according to IEC
61000-4-2
6 kV contact discharge / 8 kV air discharge
Field-bound parasitic coupling
according to
IEC 61000-4-3
10 V/m
Insulation voltage
for overvoltage category
III according to IEC 60664
with degree of
pollution 3 rated value
V 300
Degree of pollution
3
Apparent power consumed
• at 24 V for AC maximum
V·A
2
• at 240 V for AC maximum
V·A
— 4
Ambient temperature
• during operating
°C
-25 … +60
• during storage
°C
-40 … +80
• during transport
°C
-40 … +80
