Siemens ACVATIX SKB Series User Manual

10
Siemens
CM1N4564en
Smart Infrastructure
2023-10-17
Type summary
Type
Operating
voltage
Positioning
signal
Spring-return
Positioning time
Function
Time
Opening
Closing
SKB32.50
1)
-
AC 230 V
3-position
-
-
120 s
120 s
SKB32.50/F
1), 3)
SKB32.51
1)
yes
10 s
SKB32.51/F
1), 3)
SKB82.50
1)
AC 24 V
-
-
SKB82.50U
2)
SKB82.51
1)
yes
10 s
SKB82.51U
2)
SKB60
1), 4)
Standard
electronics
DC 0...10 V
4...20 mA
0...1000 Ω
-
-
10 s
SKB62
1)
yes
10 s
SKB62/F
1), 3)
SKB62U
2)
SKB62UA
2)
,
5)
Enhanced
electronics
SKB62/MO
2)
S55195-A127
Standard
electronics
Modbus RTU
1)
Approbation: CE
2)
Approbation: CE, UL
3)
Only available in France
4)
Enhanced functions (from version ..L): Direction of operation, fail-in-place
5)
Enhanced functions: Direction of operation, stroke control limit, sequence control, signal addition
Scope of delivery
The actuator, valve and accessories are supplied in separate packaging and not assembled
prior to delivery.
Accessories / spare parts
Accessories
Type
Auxiliary
switch
Double
auxiliary
switch
Potentiometer
1000 Ω
Stem heater
AC 24 V
Mechanical
stroke inverter
ASC1.6
ASC9.3
ASZ7.3
ASZ6.6
(S55845-Z108)
ASK51
Max. 2
SKB32..
-
Max.1
Max.1
Max.1
Max.1
SKB82
SKB6..
Max.1
-
-

Siemens ACVATIX SKB Series Specifications

General

Brand	Siemens
Model	ACVATIX SKB Series
Category	Controller
Language	English
