5/12
Siemens Room temperature controllers CE1N3070en
Building Technologies 01.03.2010
Notes
Mount the room temperature controller in a location where the air temperature can be
measured as accurately as possible without being adversely affected by direct solar
radiation or other sources of heat or cooling.
The controller is delivered with a fold-out stand and may be used as a "mobile" device
(Note: Pay attention to mounting location).
Mounting height is approximately 1.5 m above the floor.
The unit can be fitted to a recessed conduit box.
Fix the baseplate prior to mounting the controller. The receiver does not require a
baseplate. Connect the electrical connections and fit and secure the receiver in compli-
ance with local regulations (also refer to the separate mounting instructions).
Mount the controller on a flat wall.
If there are thermostatic radiator valves in the reference room, set them to their fully
open position.
For commissioning please refer to the Operating Instruction CE1B3070xx
Controller and receiver are maintenance-free except for the controller battery.
If battery symbol appears, the batteries are almost empty and must be replaced.
Simultaneously press the TEST and LEARN buttons on the rear side of the controller to
reset it (reset function).
Simultaneously press the OVERRIDE and LEARN buttons to reset the receiver (reset
function).
All individual settings are reset to the default values.
Mounting, installation
and commissioning
Maintenance
Change of batteries
Reset
