Siemens SCALANCE XR324WG User Manual

SCALANCE XR-300WG
Operating Instructions, 05/2017, C79000-G8976-C454-01
49
Technical specifications
7
7.1
Technical specifications of the SCALANCE XR324WG
7.1.1
24 VDC variant
The following technical specifications apply to the 24 VDC variant of the SCALANCE
XR324WG.
Technical specifications
Attachment to Industrial Ethernet
Electrical connectors Quantity 24
Connector RJ-45 jack
Properties Half/full duplex, MDI-X pinning
Transmission speed
10 / 100 Mbps
Diagnostics interface
Serial interface
Quantity
1
Connector
RJ-11 jack
Electrical data
Power supply
Design
Terminal block, 2 terminals
Rated voltage
24 VDC
Voltage range 19.2 to 28.8 VDC Safe Extra Low Voltage
(SELV)
Cable cross section
≥ 0.75 mm
2
(20 AWG)
Property
Implemented redundantly
Fusing 5 A / at least 60 V
Or power supply with LPS or NEC class 2
Current consumption
300 mA
Effective power loss
7.2 W
Permitted ambient conditions
Ambient temperature
During operation up to 3000 m
0 ℃ to +60 ℃
During storage
-40 ℃ to +85 ℃
During transportation
-40 ℃ to +85 ℃
Relative humidity
During operation at 25 ℃
≤ 95 % no condensation
Housing, dimensions and weight
Design
Rack
Housing material
Metal
Degree of protection
IP30
Dimensions (W x H x D)
482.6 x 43.6 x 127 mm
