Preface
Basic Panels 2nd Generation
4 Operating Instructions, 10/2016, A5E33293231-AB
Scope
These operating instructions are valid for all versions of the SIMATIC HMI Basic Panels. The
following naming conventions apply:
Device designation
SIMATIC HMI
Device type
Interface type
Can be configured with
KTP400 Basic
Touch device with
function keys
PROFINET
WinCC (TIA Portal) as of V13
1
KTP700 Basic PROFINET
KTP700 Basic DP
PROFIBUS
KTP900 Basic
PROFINET
KTP1200 Basic
PROFINET
KTP1200 Basic DP
PROFIBUS
1
Devices are configurable as of WinCC V13. The description in this manual relates to V14 or
higher.
Basic knowledge required
Knowledge of automation technology and process communication is necessary to
understand the operating instructions.
An understanding of the use of computers and operating systems is also required.

Siemens SIMATIC HMI KTP900 Basic Specifications

General

Display Size	9 inches
Display Type	TFT
Resolution	800 x 480 pixels
Touchscreen	Yes
Interface	PROFINET
Power Supply	24 V DC
Operating System	Windows CE
USB Port	1 x USB 2.0
Ambient Temperature (Operation)	0 to 50 °C
Ambient Temperature (Storage)	-20 to 60 °C
Relative Humidity	10% to 90% (non-condensing)
Protection Rating	IP65 (front)
Memory	12 MB
Communication Ports	Ethernet (RJ45)
Number of Colors	65536
