Commissioning the device
4.3 Parameter assignment for Comfort Panel
Comfort Panels
96 Operating Instructions, 07/2017, A5E36770603-AB
5. The "Allow manual dim up at deactivation of screensaver" for the "Blank Screen" screen
saver works as follows:
– If the option is activated, you can dim the display brightness on deactivation of the
screen saver. The brightness is increased as long as you keep pressing the touch
screen.
– If the option is deactivated, the brightness is increased to the value that was set prior
to activation of the screen saver when you touch the touch screen.
6. If you want to delay touch operation for a brief time following deactivation of the "Blank
Screen" screensaver, for example, to prevent incorrect operator inputs in connection with
option
â‘£, select the "Protect against operation within 500 ms after deactivation of
screensaver" check box.
7. Confirm your entries.
The dialog closes.
The screen saver for the HMI device has now been set. You will need to restart the HMI
device after the screen saver has been activated. The screen saver is then enabled.
Using the HMI device in password-protected security mode (Page 77)
A project can only be transferred from the configuration PC to the HMI device when at least
one data channel is configured and enabled on the HMI device. Follow the procedure below
to configure transfer mode.
If you block all data channels, the HMI device is protected against unintentional overwriting
of the project data and HMI device image.
The Control Panel is open.
Note
If you change the transfer settings while a transfer is in progress and want to confirm with
"OK", an error message is displayed.
