© Siemens AG 2021. All rights reserved
A5E50653860-AA, 01/2021
13
SIMATIC HMI
Customized Automation
SIMATIC Industrial Flat Panels V2 1500/1900 4:3/5:4
Product Information
Valid scope
This product information applies to the following industry-specific devices, which are available as standard or extended
versions:
• SIMATIC IFP1500 V2 Standard 4:3
– with Siemens logo, article number 6AV7285-6HA00-0AA0 or
– neutral design, article number 6AV7285-6HN00-0AA0
• SIMATIC IFP1500 V2 Extended 4:3
– with Siemens logo, article number 6AV7285-6HA10-0AA0 or
– neutral design, article number 6AV7285-6HN10-0AA0
• SIMATIC IFP1900 V2 Standard 5:4
– with Siemens logo, article number 6AV7285-6KA00-0AA0 or
– neutral design, article number 6AV7285-6KN00-0AA0
• SIMATIC IFP1900 V2 Extended 5:4
– with Siemens logo, article number 6AV7285-6KA10-0AA0 or
– neutral design, article number 6AV7285-6KN10-0AA0
The term "IFP devices" is used in this document to refer to all devices.
The device components are based on the following standard devices and provide the corresponding functionality:
• The front frame 4:3 (5:4) is based on the Industrial Flat Panel with capacitive multi-touch screen MT in the respective
basic version.
• The electronics and interfaces are based on the respective Industrial Flat Panel IFP V2 in the standard or extended version:
– SIMATIC IFP1500 V2,
SIMATIC IFP1500 V2 extended
– SIMATIC IFP1900 V2,
SIMATIC IFP1900 V2 extended
• The following applies to the possible operating modes:
– In "standard mode", a standard version is directly connected to the PC via a USB cable and a DVI/DisplayPort cable
≤ 5 m long.
– In "Extended mode", an extended version can be connected via a Cat. 6A Ethernet cable > 5 m and the Transceiver
Unit connected to the PC.
• Transceiver Unit, article number 6AV7860-3EH00-0AA0
You can find a description of the standard devices in the following operating instructions on the Internet, on which this
product information is based:
• Front: SIMATIC industrial LCD monitors Flat Panel, Flat Panel PRO
(https://support.industry.siemens.com/cs/ww/en/view/21899629
)
• Electronics: IFP V2, IFP V2 PRO operating instructions (https://support.industry.siemens.com/cs/ww/en/view/109767495)
This product information describes the technical differences between the devices and the respective standard devices.
Unless otherwise described in this product information, all information in the underlying operating instructions, such as
safety instructions, specifications regarding hardware, software, maintenance and service, applies to the industry-specific
devices.
The statements in this product information take precedence over statements in the underlying operating instructions, the
release notes and online help.
Figures
This document contains illustrations of the described devices. The figures can deviate from the particularities of the delivered
device.
