Siemens SIMATIC HMI Product Information

SIMATIC Industrial Flat Panels V2 1500/1900 4:3/5:4
A5E50653860-AA, 01/2021
23
Procedure
1. Switch off the device.
2. Dampen the cleaning cloth.
3. Spray the cleaning agent on the cloth and not directly on the device.
4. Clean the device with the cleaning cloth.
Cleaning the transceiver unit
Clean the enclosure surface with a damp cloth and make sure that no water enters the device.
Technical specifications
Certificates and approvals
Note
For the device itself, only the approvals shown on the rear of the device apply.
An overview of the possible approvals can be found in the underlying operating instructions on the electronics.
Technical specifications of graphics/display
Display
IFP1500 V2
Standard 4:3
IFP1500 V2
Extended 4:3
IFP1900 V2
Standard 5:4
IFP1900 V2
Extended 5:4
Display type
LCD TFT
Active display area
304.1 x 228.1 mm
376.32 x 301.06 mm
Resolution
1024 x 768 pixels
1280 x 1024 pixels
Possible colors
Up to 16.7 million
Brightness control
Yes, value range 0 to 99
1
0 = backlighting off
Backlighting
Half Brightness Life Time (MTBF
12
)
LED
50000 h
Pixel error class in accordance with
ISO 9241-307
II
Typical power consumption with external
load (0.5 A each on X61 and X62)
20 W
22 W
26 W
28 W
1
Via SetBrightness dialog: 9 to 99 (≙ 10 to 100%), via SetBrightness command line call: 0 to 99
2
MTBF: Operating hours after which the maximum brightness is reduced by half compared to the original value. MTBF is
increased by using the integrated dimming function, for example, time-controlled via screensaver or centrally via
PROFIenergy.
Technical Support
Technical support for the products covered in the manual is available in the Internet at:
• Technical support (https://support.industry.siemens.com/cs/ww/en/
)
• Support Request (http://www.siemens.com/automation/support-request)
• Service (http://support.automation.siemens.com/WW/view/en/16604318)
• Contact persons and office locations (http://www.automation.siemens.com/mcms/aspa-db/en/Pages/default.aspx)
• Training center (http://sitrain.automation.siemens.com/sitrainworld/?AppLang=en)
Additional information on SIMATIC products is available in the Internet at:
• Industry Portal (http://www.automation.siemens.com/_en/portal/index.htm
)
• SIMATIC Documentation Collection (http://www.siemens.com/simatic-tech-doku-portal)
