Installing
4.2 Technical data of the telescopic rails
SIMATIC IPC847C
22 Getting Started, 12/2010, A5E02669190-02
CAUTION
The mounting screws of the telescopic rails may not protrude more than 5 mm into the
enclosure.
CAUTION
Risk of injury!
It is not permitted to install the device only on the 19-inch brackets of the front panel.
Note
For vertical operation, install the device on a horizontal metal base and secure it against
tilting. The following RITTAL module panels are available:
Rittal type TE 7000.620, Rittal type VR 3861.580, Rittal type DK 7063.710. Note the
information of the switch cabinet supplier.
4.2 Technical data of the telescopic rails
Ultimate load per pair At least 23 kg
Full extraction length At least 470 mm
Rail thickness Maximum 9.7 mm
Mounting screws M5 x 6 mm
