Services, Diagnosis and Data Saving
5-8 SINUMERIK 801
Start-Up
5.3 Data Saving
5.3.1 Internal Data Saving
Data saving After all MD has been started up, the password must be closed so as to save
data and call the data again rapidly next time.
Operating sequence:
Diagnostics
Start-up
Save data
Save machine data, set data, machining data, leadscrw error compensation
data, etc. in the permanent memory. Recall them again via Start-up switch
position 3 or by selecting menu “Power-up with saved data”.
Notice
If the fuction “record reference point” has been executed (with MD34210),
do
approach reference point again after system power up with saved data!
5.3.2 External Data Saving
Purpose In case of any product fault and subsequent maintenance, the machine tool
builder / end user is requested to fill in the Warranty Card – SINUMERIK 801
delivered in the package so that the setting data can be recovered
immediately by Siemens after product has been replaced or maintained.
Hereinbelow is relevant data sheet described in the Warranty Card.
1. Machine Data
OEM Value
Data Definition Unit
X-axis Z-axis Spin.
Setting value:
30134 Setpoint output is unipolar -
30600 Fixed-value positions of axis with
G75 (position no.)
mm
31020 Encoder markings per revolution
(encoder no.)
IPR
31030 Pitch of leadscrew mm
31050
[0]
Denominator load gearbox (control
parameter No.)[0]
-
31050
[1]
Denominator load gearbox (control
parameter No.)[1]
-
31060 Numerator load gearbox (control -
