32 SIPROTEC 4/5, Injection Unit 7XT71, Product Information
C53000-B1174-C128-7, Edition 09.2016
Settings
Constructive Design
Firmware Version of the Protection Device 7UMxx
Terminals 12, 14 (V
Meas
1) and 11, 13 (V
Meas
2)
Output voltage V
Meas
1/2 < ±15 V
Maximum output current at V
Meas
1/2 < ±2 mA, short-circuit proof
Output frequency at V
Output
A/B (setting with DIP switch)
Setting range 0.5 to 4.0 Hz ±5%
Settings 0.5 Hz, 1.0 Hz, 1.5 Hz, 2.0 Hz,
2.5 Hz, 3.0 Hz, 3.5 Hz, 4.0 Hz
Default setting 1.5 Hz
Housing 7XP20, 1/6 19 inch case
Dimensions
7XT7100-0BA00 312.8 mm x 75.0 mm x 243.5 mm /
12.31 inch x 2.95 inch x 9.59 inch
with Z angles and terminal strip
7XT7100-0EA00 266.0 mm x 75.0 mm x 235.5 mm /
10.47 inch x 2.95 inch x 9.27 inch
with terminal strip
Mass
7XT7100-0BA00 2.3 kg
7XT7100-0EA00 2.1 kg
Degree of protection acc. to EN 60529 (flush mount variant)
Front IP51
Housing and terminals IP20
Degree of protection acc. to EN 60529 (surface mount variant)
Device IP20
7UM62 from V4.00
7UM85 from V7.30
