Siemens SITOP User Manual

Selectivity modules
Manual, 01.2017, C98130-A7579-A1-2-7629
47
Technical data
6
Note
Technical data apply f
or a rated input voltage, rated load and 25 °C ambient temperature if
nothing else is specified.
6.1
Input
6EP1961-2BA00
6EP1961-2BA11
6EP1961-2BA31
6EP1961-2BA51
6EP1961-2BA61
6EP1961-2BA21
6EP1961-2BA41
Input
Regulated DC voltage
1*)
Regulated DC voltage
Regulated DC voltage
Rated voltage U
in rated
24 V
24 V
24 V
Voltage range
22 - 30 V
22 - 30 V
22 - 30 V
Overvoltage strength 35 V; 100 ms 35 V 35 V
Input current at U
in rated
40 A 12 A 40 A
1*)
SITOP select (6EP1961-2BA00) cannot be operated with the DC-UPS module 40 A
(6EP1931-2FC21/-2FC42).
6.2
Output
6EP1961-2BA00
6EP1961-2BA11
6EP1961-2BA31
6EP1961-2BA51
6EP1961-2BA61
6EP1961-2BA21
6EP1961-2BA41
Output
Regulated DC voltage
Regulated DC voltage
Regulated DC voltage
Output voltage
U
in
- approx. 0.3 V
U
in
- approx. 0.2 V
U
in
- approx. 0.2 V
Total tolerance Corresponding to the supply-
ing input voltage
Corresponding to the supply-
ing input voltage
Corresponding to the supply-
ing input voltage
Number of outputs
4
4
4
Output current/up to
60 °C/each output/rated
value
10 A 3 A 10 A
