Singer 14T968DC User Manual

Two-Thread Overedge (narrow) page 7
 Disengage Spreader. The Upper Looper has a hole for the thread on the top of the
looper. If the stitch requires that the looper be engaged but not threaded, then the
Spreader is used. The Spreader simply plugs-in (or closes) the looper’s hole. The
Spreader is disengaged when the Upper Looper is engaged/operative and threaded.
The Spreader is used with a stitch that requires only one looper thread. With
the help of the Spreader, the single looper thread wraps around the fabric’s
edge.
1. Lower the white handle on the Spreader to open the eye of the Upper
Looper.
 Thread Upper Looper with regular overlock thread.
1. Raise the Presser Foot to release the
tension disks. Thread the Lower
Looper as illustrated 1-9.
2. Pass thread from back to the
front through the thread
guide.
Spreader Engaged Spreader Disengaged
Eye of Looper

Singer 14T968DC Specifications

General

Presser Foot	Snap-On
Free Arm	Yes
Needle System	ELx705
Speed	1300 stitches per minute
Stitch Types	Overlock, Rolled Hem
Number of Threads	2-3-4-5
