Singer 3232 User Manual

Automatic Needle Threader
- Raise the needle to its highest position.
- Press lever (A) down as far as it will go.
- The threader automatically swings to the threading position
(B).
- Pass thread around thread guide (C).
- Pass the thread in front of the needle around the hook (D)
from bottom to top.
- Release lever (A).
- Pull the thread through the needle eye.
Turn power switch to off ("O")!
Attention:
19
EN
1
2
A
B
D
C
A
C
A
C
B
D

Singer 3232 Specifications

General

Stitch Patterns	32
Buttonhole Style	1-Step
Built-in Needle Threader	Yes
Free Arm	Yes
Adjustable Stitch Length	Yes
Adjustable Stitch Width	Yes
Automatic Bobbin Winding	Yes
Type	Mechanical
Stitch Width	5mm
Presser Feet	All-purpose, Zipper, Buttonhole, Button Sewing
Stitch Length	4mm
Maximum Sewing Speed	750 stitches per minute
Voltage	120V
Weight	12.3 lbs
Bobbin Type	Front Load
